Samtec TSM Series Vertical Surface Pin Header, 2 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded, Gold Plated TSM-102-02-S-SV
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 5.4A |
| Model | TSM-102-02-S-SV |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Plating used | Au or Sn over 50 μ" (1.27 μm) Ni |
Key Features
- The pin header features a vertical orientation suitable for board-to-board connections.
- It has 2 unshrouded contacts made from phosphor bronze with gold plating for corrosion resistance.
- The pitch between contacts is 2.54 mm with a single row configuration.
- Constructed with a liquid crystal polymer housing ensuring durability under operating temperatures from -55°C to 125°C.
- Surface mount type designed for solder termination on PCB boards.
- Rated for a maximum current of 5.4 A and maximum voltage of 475 V.
- This connector is RoHS compliant and suitable for electronic component manufacturing and repair.
- Gold plating thickness is Au or Sn over 50 microinches (1.27 micrometers) of nickel.
Product Description
Samtec TSM-102-02-S-SV Vertical Surface Pin Header is a precision-engineered electronic connector designed for robust board-to-board connections in a variety of industrial and electronic applications. With 2 gold-plated phosphor bronze contacts arranged in a single row, the connector offers reliable electrical conductivity and durability.
The connector utilizes a liquid crystal polymer housing that provides excellent mechanical strength and thermal stability, operating efficiently within a temperature range of -55°C to 125°C. Its 2.54 mm pitch and vertical orientation make it compatible with standard printed circuit board layouts.
This unshrouded pin header is surface mount type, ideal for solder-based PCB assembly processes. Rated for up to 5.4 A current and 475 V voltage, it supports demanding power and signal transmission requirements. The gold plating over nickel ensures strong corrosion resistance and consistent contact quality over its lifecycle.
The Samtec TSM series connectors comply with RoHS environmental standards, reflecting commitment to reduced hazardous substances in electronics manufacturing. Its compact size and reliable performance suit uses in electronic components production, power supply assemblies, telecommunications equipment, and industrial control systems.
The pin header has 2 contacts with 2.54 mm pitch and a single vertical row. Contacts are phosphor bronze with gold plating for high reliability. Liquid crystal polymer housing offers strong mechanical and thermal properties.
Designed for surface mount solder termination on PCBs. Operating temperature ranges from -55°C to 125°C for versatile environments. Rated maximum current is 5.4 A and voltage 475 V for consistent performance. RoHS compliant, suitable for environmentally conscious electronics manufacturing.
Gold plating thickness is Au or Sn over 50 microinches of nickel for corrosion protection. Use cases include industrial, telecommunications, electronic assembly, and control systems.
For detailed design and mechanical parameters, engineers and purchasers can refer to Samtec technical documentation and RoHS certificates. Explore more industrial electronics and PCB header solutions at EnvMart.
Explore more products in our PCB Headers category.
