Samtec Right Angle Through Hole PCB Header, 8 Contact, 4.19 mm Pitch, 2 Row, Shrouded IPBT-104-H1-T-D-RA-GP

The Samtec IPBT-104-H1-T-D-RA-GP is a precision-engineered right angle through hole PCB header designed to provide reliable electrical connections in complex electronic assemblies. Featuring 8 contacts with a 4.19 mm pitch arranged in 2 rows, this shrouded header ensures safe mating and unmating with mating connectors, protecting the contacts from damage and contamination.

This model employs high-quality Liquid Crystal Polymer housing that offers excellent mechanical strength and thermal resistance, making it suitable for harsh industrial environments. The copper alloy contacts with selective gold or tin plating guarantee excellent conductivity and corrosion resistance, essential for maintaining signal integrity and power delivery.

Rated at 7.1 amps, it supports moderate current loads typical in power and signal board-to-board applications. Its male contact gender facilitates interfacing with matching female connectors, while its through hole mount style ensures strong mechanical stability on printed circuit boards.

Engineered for operation from -55°C up to 125°C, this PCB Header fits applications from industrial automation to telecommunications equipment that demand wide temperature tolerance and reliability. The consistent row and contact pitch of 4.19 mm supports precise positioning and soldering during assembly processes.

Applications for the IPBT series include power distribution boards, connector interfaces in electronic instruments, and industrial control panels. The shrouded design improves operational safety and machining tolerance, reducing the risk of misalignment and damage during both assembly and in-field usage.

Rated 7.1 amp current capacity for dependable power delivery. Robust Liquid Crystal Polymer housing for thermal and mechanical endurance. Copper alloy contacts with gold or tin plating for high conductivity and corrosion protection.

Right angle orientation with 2 rows and 8 contacts at 4.19 mm pitch. Through hole mount type for secure PCB integration. Shrouded contacts offer enhanced protection and connector reliability. Wide operating temperature range from -55°C to 125°C.

Designed to support board-to-board connection systems. Male contact gender and solder termination for industrial electronic assembly processes.

Samtec IPC-compliant headers are widely utilized in electronic manufacturing, industrial automation, power management, and telecommunications. EnvMart supports customers seeking high-performance PCB connectors suitable for demanding applications.
