Samtec Right Angle Through Hole PCB Socket, 20-Contact, 2 Row, 2.54 mm Pitch, 6.3A, 655V SSQ-110-02-T-D-RA

Samtec SSQ-110-02-T-D-RA is a high-quality right angle through hole PCB socket designed for electronic components requiring robust and reliable board-to-board connectivity. Featuring a 20-contact, 2-row configuration with a 2.54 mm pitch, this PCB socket is ideal for use in industrial electronics, telecommunications, and computing equipment.

The socket's housing is made from liquid crystal polymer, which provides excellent durability and thermal stability across its operating temperature range of -55°C to 105°C. The contacts are manufactured from phosphor bronze with tin plating, ensuring strong electrical performance and corrosion resistance.

Supporting a current rating of 6.3 amps per pin and a voltage rating of up to 465VAC or 655VDC, this connector supports demanding electrical applications. The right angle orientation facilitates PCB assembly in tight or complex spaces. The standard contact normal force of 125 grams provides secure and reliable connections, enhancing signal integrity and mechanical stability.

Designed for board-to-board connector systems, the SSQ series ensures compatibility with multiple industrial and commercial electronics platforms. It is rated for up to 100 insertion cycles, maintaining a contact plating gold thickness of 10 microinches (0.25 micrometers) for extended durability.

Supports a rated current of 6.3 amperes per pin for efficient power handling. Constructed with liquid crystal polymer housing ensuring durability and stability. Features a right-angle orientation for versatile PCB mounting options.

Contact material is phosphor bronze with tin plating for corrosion resistance. Operates within a temperature range of -55°C to 105°C for harsh environment suitability. Designed with a standard contact normal force of 125 grams (4.4N) for reliable electrical contact.

Rated for a voltage of 465VAC and 655VDC for broad electrical applications. Connector system supports board-to-board connections with a 2-row configuration. Reliability includes maximum 100 mating cycles with gold plating thickness of 10µ" (0.25µm) Au.

This PCB Socket is suitable for industrial electronic assemblies, telecommunications hardware, control systems, and other applications requiring precision electrical connectivity. Select the Samtec SSQ-110-02-T-D-RA for durable and performance-optimized PCB connector solutions. Explore more electronic components and connectors from leading brands on EnvMart.
