Samtec SSM Series Straight Surface PCB Socket 5-Contact 1 Row 2.54 mm Pitch 572V 5.2A SSM-105-L-SV-BE-TR

The Samtec SSM-105-L-SV-BE-TR is a high-quality straight surface PCB socket from the esteemed SSM series by Samtec. It features a 5-contact, single-row design with a 2.54 mm pitch, making it suitable for precise board-to-board connections in various electrical and electronic devices.

This socket employs a black liquid crystal polymer housing which provides excellent insulation and durability under demanding conditions. The contact material is phosphor bronze, plated with gold to ensure a low-resistance and corrosion-resistant connection, essential for stable electrical performance.

It supports a voltage rating of 572 V and a current rating of 5.2 A per pin, with two pins powered, meeting rigorous design requirements. The socket operates reliably in a temperature range from -55°C to 125°C, which accommodates diverse industrial environments.

The tiger claw contact system applies an average normal force of 125 grams (1.21 N), guaranteeing consistent contact pressure and reducing connection failures. The surface mount termination type and straight orientation enable straightforward integration on PCBs.

This socket is designed for use in electronic manufacturing, industrial controls, telecommunications, and other commercial applications requiring dependable PCB connectors. It accommodates single and double row setups up to 80 pins, extending its versatility.

5-contact, single row design with 2.54 mm pitch. Liquid crystal polymer housing for insulation. Phosphor bronze contacts with gold plating for conductivity. Operating voltage up to 572 V and current rating of 5.2 A per pin.

Temperature range from -55°C to 125°C. Tiger claw contact system with 125 grams normal force. Surface mount termination and straight orientation. Suitable for industrial, laboratory, and commercial PCB applications. Explore the wide range of PCB Sockets available at EnvMart for your electronic component needs.
