Samtec FLE Series Vertical Surface PCB Socket, 10-Contact, 2 Row, 1.27 mm Pitch, Solder Termination FLE-105-01-G-DV-A-K

Samtec FLE-105-01-G-DV-A-K is a reliable and cost-effective vertical surface PCB socket featuring 10 contacts configured in 2 rows with a 1.27 mm pitch, designed for board-to-board connector systems.

This socket employs solder termination type, ensuring strong and secure solder connections suitable for various electronic assembly requirements.

The housing material consists of black liquid crystal polymer, providing robust insulation and mechanical strength at a wide operational temperature spanning from -55°C up to 125°C.

Phosphor bronze contact material with gold plating guarantees excellent electrical conductivity, durability, and resistance to wear and corrosion, suitable for demanding industrial and electronic applications.

Compliant with RoHS standards, this socket supports a current rating of 2.9 A and is specifically designed for vertical orientation mounting on printed circuit boards, making it ideal for pass-through connection applications.

The FLE series is well-regarded for balancing performance and cost-efficiency, making this socket suitable for industrial electronics manufacturing, telecommunications equipment, and consumer electronics.

The socket supports a current rating of 2.9 A. It uses solder termination for reliable electrical connections. Housing is made of black liquid crystal polymer material. Contacts are phosphor bronze with gold plating for enhanced conductivity and corrosion resistance.

The operating temperature range is from -55°C to 125°C. This product complies with RoHS standards. Designed for vertical orientation and surface mounting. Ideal for pass-through PCB connector applications. Part of the FLE series known for cost-effective and reliable sockets.
