Crydom Solid State Relay Panel Mount 25 A Load 280 Vrms Load 280 Vrms Control CWA2425-10
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 33mm |
| Length | 45.7mm |
| Model | CWA2425-10 |
| IP Rating | IP20 |
| Width | 22.6mm |
| Mount Type | Panel |
| Output type | SCR |
| Series | CWA |
| Maximum Operating Temperature | 80°C |
| Capacitance | 8pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Screw |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 25A |
| Standards/Approvals | RoHS |
| Minimum Load Voltage | 280V |
| Minimum Control Voltage | 90V |
| Off State Leakage Current | 100μA |
Key Features
- Designed for panel mounting and supports a maximum load current of 25 amps.
- Operates at a maximum load voltage of 280 Vrms with a minimum control voltage of 90 V.
- Features zero cross switching for reduced electrical noise and enhanced switching performance.
- Equipped with screw terminal type connections and an integrated removable fingerproof cover for safety.
- Compact dimensions of 45.7mm length, 33mm height, and 22.6mm width enable easy installation.
- SCR output type with LED status indicator for operational monitoring.
- Designed to operate between temperatures of -40°C minimum and 80°C maximum.
- Low off-state leakage current of 100μA and capacitance of 8pF for reliable operation.
Product Description
The Crydom CWA2425-10 is a high-quality solid state relay designed for panel mount applications requiring reliable switching under demanding conditions. It supports a maximum load current of 25 Amps and can handle load voltages up to 280 Vrms, with control voltages ranging from 90 V to 280 Vrms. This model features zero cross switching functionality which minimizes electrical noise and enables smoother switching transitions.
With its SCR output type, the relay offers robust control with an LED status indicator to provide immediate visual feedback on operation. The unit employs screw terminals and includes an integrated removable fingerproof cover, enhancing user safety during installation and maintenance. Its compact dimensions (45.7mm long, 33mm high, and 22.6mm wide) permit easy integration into control panels within industrial, manufacturing, automation, and HVAC systems.
Operating within a wide temperature range from -40°C to 80°C, the Crydom CWA2425-10 solid state relay delivers consistent performance for industrial automation, electrical control, and process control environments. Its IP20 rating protects against solid objects and finger access, making it suitable for indoor panel applications. The relay features a low off-state leakage current of 100 microamps and capacitance of 8 picofarads, contributing to low power loss and reliable operation.
This model complies with RoHS standards, ensuring that it meets environmental safety requirements critical for modern industrial practices. Panel mount solid state relay with 25 A maximum load current. Supports load voltage up to 280 Vrms and control voltage between 90 V and 280 Vrms.
Zero cross switching function reduces electrical noise and wear. SCR output type with LED status indicator for operation monitoring. Screw terminal connections with integrated removable fingerproof cover. Compact dimensions ease integration into electrical control panels.
Operates reliably within -40°C to 80°C temperature range. Low off-state leakage current (100μA) and capacitance (8pF). Indoor use with IP20 rating protection. RoHS compliant ecological standards.
This Crydom Solid State Relay series is ideal for industrial automation, manufacturing equipment, HVAC systems, and electrical control panel applications. Explore EnvMart for more high-quality relays and automation components to optimize your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum load current of 25 amps.
It can handle load voltages up to 280 Vrms.
The minimum control voltage for this relay is 90 V.
It features zero cross switching, which reduces electrical noise during operation.
The relay has compact dimensions of 45.7mm in length, 33mm in height, and 22.6mm in width.
It operates reliably within a temperature range of -40°C to 80°C.
This model features an SCR output type.
It is equipped with screw terminal type connections for easy installation.
Yes, it includes an integrated removable fingerproof cover for enhanced safety.
It has an IP20 rating, which protects against solid objects and finger access, suitable for indoor use.
The off-state leakage current is 100 microamps.
Yes, it complies with RoHS standards, ensuring it meets environmental safety requirements.
