Wurth Elektronik 3631 Series Pluggable Terminal Block, 12-Contact, 3.5 mm Pitch, 1 Row, Male Connector, 10A 691363110012

Name: Wurth Elektronik 3631 Series Pluggable Terminal Block, 12-Contact, 3.5 mm Pitch, 1 Row, Male Connector, 10A 691363110012
Brand: Wurth Elektronik
SKU: 159479
Price: 9.33 USD
Availability: InStock



Category Pluggable Terminal Block Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	1.6kV
Brand	Wurth Elektronik
Colour	Green
Orientation	Horizontal
Current	10A
Length	42mm
Depth	19.3mm
Width	10.4mm
Housing Material	Polyamide
Series	3631
Number of Rows	1
Pitch	3.5mm
Standards/Approvals	RoHS
Number of Contacts	12
Connector Gender	Male
Minimum Wire Size mm²	0.081mm²
Maximum Wire Size mm²	1.31mm²
Minimum Wire Size AWG	28AWG
Maximum Wire Size AWG	16AWG
Wire Connection Method	Solder

Key Features

Supports a maximum current of 10 amperes with high voltage tolerance of 1.6kV.
Features a male connector with horizontal orientation for versatile mounting.
Constructed with polyamide housing material ensuring robust insulation and mechanical strength.
Compatible with wire sizes ranging from 28 AWG to 16 AWG and 0.081 mm² to 1.31 mm².
Complies with RoHS standards, ensuring environmentally friendly material use.
Color-coded green for easy identification and application.

Product Description

Wurth Elektronik 691363110012 Pluggable Terminal Block is an industrial-grade electrical connector designed for reliable soldered wire connections in PCB and electronic assemblies. Its 12-contact configuration with a 3.5 mm pitch and single-row layout supports a current rating of 10A and withstands voltages up to 1.6kV, making it suitable for a wide range of industrial and electronic applications.

The terminal block features a male connector with horizontal orientation, facilitating straightforward installation onto PCBs and modular configurations. The polyamide housing provides excellent durability and electrical insulation, while the green color enhances visual distinction during assembly and maintenance.

Wire compatibility encompasses AWG sizes from 28 to 16 and cross-sectional areas between 0.081 mm² and 1.31 mm², allowing flexibility for different wiring requirements. This terminal block adheres to RoHS compliance, ensuring the component meets strict environmental standards.

Its compact dimensions (42 mm length, 10.4 mm width, 19.3 mm depth) contribute to space-efficient PCB designs. The 3631 series from Wurth Elektronik is known for modularity and robust performance, ideal for industrial electronics, power connectors, automation systems, and other commercial electrical devices.

Supports 12 contacts with 3.5 mm pitch in one row. Rated for currents up to 10A and voltage withstand of 1.6kV. Constructed with durable polyamide green housing for insulation. Suitable for wire sizes 28 AWG to 16 AWG and 0.081 mm² to 1.31 mm².

Connector gender is male with horizontal orientation. Complies with RoHS environmental standards. Compact dimensions enhance PCB space utilization.

This product is manufactured in China and is supplied new, meeting industrial quality expectations. Discover more premium terminal block solutions and components in our Electronics & Electricals category at EnvMart.
