Wurth Elektronik 385 Series Pluggable Terminal Block, 18-Contact, 5 mm Pitch, 1 Row, 14A Current, 2.5kV 691385700018
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 2.5kV |
| Brand | Wurth Elektronik |
| Colour | Grey |
| Orientation | Vertical |
| Current | 14A |
| Length | 90mm |
| Depth | 16mm |
| Width | 15.5mm |
| Housing Material | Polycarbonate |
| Series | 385 |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 18 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 3.31mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Solder |
Key Features
- Current rating of 14 amperes supports medium power electrical connections.
- Constructed of durable polycarbonate housing for mechanical strength and electrical insulation.
- Male connector gender with solder wire connection method provides secure and robust electrical contact.
- Compact dimensions with 90 mm length, 15.5 mm width, and 16 mm depth optimize PCB space.
- Compatible with wire sizes from 24 AWG to 12 AWG and cross-sectional areas between 0.2 mm² and 3.31 mm².
- Vertical orientation facilitates ease of assembly and integration into industrial control equipment.
- Compliant with RoHS standards guaranteeing environmental safety and no hazardous substances.
Product Description
Wurth Elektronik 691385700018 is a 385 Series Pluggable Terminal Block designed for reliable electrical connections in industrial and electronics manufacturing environments. It consists of 18 contacts arranged in a single row with a 5 mm pitch, accommodating wire sizes from 24 AWG to 12 AWG and suitable cross-sectional areas from 0.2 mm² to 3.31 mm². This terminal block supports a maximum current rating of 14 amperes and can withstand voltages up to 2.5 kV, making it suitable for moderate voltage and current applications.
The housing is made of polycarbonate, providing robust mechanical protection and efficient electrical insulation. The male connector type with solder wire connection method ensures a secure and permanent electrical join. The compact size with dimensions of 90 mm length, 15.5 mm width, and 16 mm depth allows for efficient PCB layout in densely populated electronic assemblies.
This product complies with RoHS directives, ensuring environmental safety by limiting hazardous substances. Its vertical orientation simplifies installation in control panels, industrial automation systems, and power distribution modules.
Current rating of 14A suitable for moderate power applications. Voltage withstand rating of 2.5kV ensures high insulation strength. Polycarbonate housing offers durability and electrical safety. Male connector design with solder wire connection provides reliability.
Compact dimensions for space-efficient PCB design. Suitable for 24 AWG to 12 AWG wire sizes. Compliant with RoHS environmental standards. Ideal for industrial, manufacturing, and automation electronics applications.
This terminal block is widely used in electronic manufacturing, industrial automation, HVAC controllers, and power electronics circuits where secure, soldered electrical connections are required. It is suitable for both laboratory and commercial equipment assembly requiring reliable pluggable terminal solutions.
Explore additional Wurth Elektronik components and related industrial electronics on EnvMart to complement your PCB designs and electronic assemblies.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block has a current rating of 14 amperes, making it suitable for moderate power applications.
It can withstand voltages up to 2.5 kV, ensuring high insulation strength for electrical connections.
This model is compatible with wire sizes ranging from 24 AWG to 12 AWG and cross-sectional areas from 0.2 mm² to 3.31 mm².
The terminal block measures 90 mm in length, 15.5 mm in width, and 16 mm in depth, allowing for efficient PCB layout.
It is constructed from polycarbonate, providing mechanical strength and electrical insulation.
This model features 18 contacts arranged in a single row with a 5 mm pitch.
It uses a male connector type with a solder wire connection method for secure electrical contact.
The terminal block is designed for vertical orientation, facilitating ease of assembly in control panels.
Yes, it complies with RoHS standards, ensuring environmental safety by limiting hazardous substances.
It is widely used in electronic manufacturing, industrial automation, HVAC controllers, and power electronics circuits.
The pitch of this terminal block is 5 mm, which is standard for many electronic applications.
This terminal block is manufactured in India.
