Abracon 12.28 MHz Crystal Unit Surface Mount 2-Pin 11.4mm x 4.7mm x 4.1mm ABLS-12.288MHz-D-3-Y-T

Abracon ABLS-12.288MHz-D-3-Y-T is a high-precision crystal unit designed for surface mount applications. Operating at a stable frequency of 12.28 MHz with a frequency tolerance of ±25 ppm and frequency stability of ±30 ppm, this crystal unit offers dependable timing and frequency control for electronic devices.

The component features a two-pin surface mount package with compact dimensions of 11.4 mm length, 4.7 mm width, and 4.1 mm height, allowing efficient space utilization on PCBs. Its load capacitance of 18 pF and series resistance of 50 Ω contribute to optimized electrical characteristics and minimized signal loss.

Built to perform reliably across an operating temperature range from -40°C to 85°C, this crystal unit is suitable for industrial, telecommunications, computing, and wireless applications that require stable frequency sources. The device complies with RoHS standards, underscoring its environmental safety and quality assurance.

Standard frequency of 12.28 MHz ensures precise oscillation control. Surface mount type designed for efficient PCB integration. Compact dimensions enable versatile application in compact electronic devices. Frequency tolerance ±25 ppm and stability ±30 ppm provide high reliability.

Load capacitance of 18 pF ensures compatibility with various circuits. Series resistance of 50 Ω reduces signal attenuation and power loss. Wide temperature range from -40°C to 85°C supports harsh environments. RoHS compliant for environmental and safety considerations.

This crystal unit is ideal for use in computers, modems, microprocessors, and wireless applications requiring precise frequency control. Its surface mount design supports automated manufacturing processes, increasing production efficiency.
