Wurth Elektronik WR-TBL Series Pluggable Terminal Block 8-Contact 5.08 mm Pitch 1 Row 16A 2.5kV Copper Housing 691305530008
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 2.5kV |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Vertical |
| Current | 16A |
| Length | 42.64mm |
| Depth | 8.6mm |
| Width | 12mm |
| Housing Material | Copper |
| Series | WR-TBL |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | RoHS, REACH, cULus |
| Number of Contacts | 8 |
| Connector Gender | Male |
| Wire Connection Method | Solder |
Key Features
- Designed for currents up to 16A ensuring robust electrical performance.
- Constructed with copper housing for excellent conductivity and durability.
- Features a male connector gender facilitating solder wire connections.
- Supports high voltage operation up to 2.5kV for industrial applications.
- Compact dimensions measuring 42.64mm length, 12mm width, and 8.6mm depth.
- Compliant with RoHS, REACH, and cULus standards for environmental and safety regulations.
- Single-row design simplifies PCB assembly with one row of contacts.
- Green color coding aids in visual component identification.
Product Description
Wurth Elektronik 691305530008 Pluggable Terminal Block is a precision-engineered component designed for reliable electrical connections in electronic assemblies and industrial applications. This terminal block features 8 contacts arranged in a single row with a 5.08 mm pitch, providing an optimal balance between space-saving and ease of wiring.
The terminal block uses a copper housing to ensure excellent electrical conductivity and mechanical strength. Its male connector gender and vertical orientation facilitate secure solder wire connection to the PCB, making it ideal for printed circuit board integration.
Rated for a current capacity of 16 amperes and a voltage withstand of 2.5 kilovolts, this component supports demanding electrical loads while maintaining safety and reliability. The green-colored housing aids technicians in quick identification and proper installation.
With overall compact dimensions of 42.64 mm in length, 12 mm in width, and 8.6 mm in depth, the WR-TBL series terminal block suits tight assembly spaces. Certified under RoHS and REACH for hazardous substance compliance and cULus for safety standards, it meets global regulatory requirements.
Designed for currents up to 16A ensuring robust electrical performance. Constructed with copper housing for excellent conductivity and durability. Features a male connector gender facilitating solder wire connections. Supports high voltage operation up to 2.5kV for industrial applications.
Compact dimensions measuring 42.64mm length, 12mm width, and 8.6mm depth. Compliant with RoHS, REACH, and cULus standards for environmental and safety regulations. Single-row design simplifies PCB assembly with one row of contacts.
Green color coding aids in visual component identification.
This terminal block is widely used in electronics manufacturing, industrial control systems, and power distribution modules. It allows secure, pluggable connections which are essential for modular design, maintenance, and upgrades in electronic devices.
Explore more products in the Pluggable Terminal Blocks category at EnvMart for comprehensive electronic assembly solutions from leading manufacturers including Wurth Elektronik.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block is rated for a current capacity of 16 amperes.
It supports high voltage operation up to 2.5 kilovolts (kV).
The dimensions are 42.64 mm in length, 12 mm in width, and 8.6 mm in depth.
It features 8 contacts arranged in a single row.
The housing is constructed from copper, ensuring excellent electrical conductivity.
The contact pitch is 5.08 mm.
It features a male connector gender, facilitating solder wire connections.
Yes, it is compliant with RoHS, REACH, and cULus standards.
The terminal block has a vertical orientation.
It uses a solder wire connection method.
It is widely used in electronics manufacturing, industrial control systems, and power distribution modules.
The housing is green, which aids in visual component identification.
