Bourns Surface Mount Common Mode Line Filter 1.1 μH ±35% 2A 0504 Package SRF0504
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 4.8mm |
| Length | 5mm |
| Model | SRF0504 |
| Depth | 5.2mm |
| Packaging | 1000 pieces per 13 in Reel |
| Series | SRF0504 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance Range | 0.60 to 6.0 μH |
| Inductance | 1.1μH |
| Standards/Approvals | RoHS |
| Package/Case | 0504 |
| Maximum DC Current | 2A |
| Maximum DC Resistance | 40mΩ |
| Inductance Tolerance | ±35 % |
| Termination Style | Tin Plated Red Copper(DSn) |
| Maximum Self Resonant Frequency | 1200MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- The filter uses a ferrite core for effective EMI suppression.
- Package size is 0504 with a wirewound inductor construction.
- Rated for operating temperatures from -40°C to 125°C.
- Maximum DC resistance is 40 mΩ ensuring minimum power loss.
- Self-resonant frequency reaches up to 1200 MHz for high-frequency applications.
- Compliance with RoHS and automotive standard AEC-Q200 ensures quality and reliability.
- Termination style is tin plated red copper (DSn) for robust soldering.
- Packaged as 1000 pieces on a 13-inch reel for efficient assembly processes.
Product Description
Bourns SRF0504 is a surface mount common mode line filter designed to provide efficient EMI suppression in demanding electronic applications. Featuring a ferrite core and wirewound construction, it delivers an inductance of 1.1 μH with a tolerance of ±35% and can handle a maximum DC current of 2 A. The compact 0504 package measuring 5 mm in length, 4.8 mm in height, and 5.2 mm in depth enables its use in dense PCB layouts.
Designed to operate reliably in temperatures ranging from -40°C to 125°C, the SRF0504 filter offers maximum DC resistance of just 40 mΩ, optimizing power efficiency. Its self-resonant frequency up to 1200 MHz makes it suitable for high-frequency EMI filtering tasks. This component complies with RoHS directives and meets automotive standard AEC-Q200, stressing its quality and consistency for automotive and industrial use.
The termination style employs tin plated red copper (DSn) providing excellent solderability and connection stability. Packaging consists of 1000 pieces loaded onto a 13-inch reel, suitable for automated pick-and-place SMT assembly lines. Common applications include EMI suppression in power line filters and signal integrity enhancement in industrial and commercial electronic equipment.
The filter uses a ferrite core for effective EMI suppression. Package size is 0504 with a wirewound inductor construction. Rated for operating temperatures from -40°C to 125°C. Maximum DC resistance is 40 mΩ ensuring minimum power loss.
Self-resonant frequency reaches up to 1200 MHz for high-frequency applications. Compliance with RoHS and automotive standard AEC-Q200 ensures quality and reliability. Termination style is tin plated red copper (DSn) for robust soldering.
Length measures 5 mm, height 4.8 mm, and depth 5.2 mm to fit compact PCB layouts. Packaged as 1000 pieces on a 13-inch reel for efficient assembly processes.
Ideal for industrial, automotive, and commercial electronics applications where compact EMI filtering solutions are required, the Bourns SRF0504 ensures signal integrity and compliance with electromagnetic compatibility standards. Explore related categories and Bourns products on EnvMart for comprehensive electronics component solutions.
Explore more products in our Surface Mount Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance of the Bourns SRF0504 is 1.1 μH with a tolerance of ±35%.
This model can handle a maximum DC current of 2 A.
The dimensions of the SRF0504 are 5 mm in length, 4.8 mm in height, and 5.2 mm in depth.
The self-resonant frequency of this component reaches up to 1200 MHz, making it suitable for high-frequency applications.
The filter operates reliably in temperatures ranging from -40°C to 125°C.
The maximum DC resistance is 40 mΩ, which helps optimize power efficiency.
The filter uses a ferrite core for effective EMI suppression.
It is packaged as 1000 pieces on a 13-inch reel, suitable for automated pick-and-place SMT assembly lines.
The termination style is tin plated red copper (DSn), providing excellent solderability and connection stability.
Yes, it complies with RoHS directives and meets the automotive standard AEC-Q200.
This model is suitable for EMI suppression in power line filters and enhancing signal integrity in industrial and commercial electronic equipment.
The inductor features a wirewound construction, which is typical for this type of component.
