Samtec Straight Through Hole PCB Header 8 Contacts 1.27 mm Pitch 2 Row Shrouded TFM-104-01-L-D-WT
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.2A |
| Model | TFM-104-01-L-D-WT |
| Mount Type | Through Hole |
| Special Features | Screw down, weld tab and solder nail options available for most rugged requirements |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TFM |
| Termination | Through-hole, surface mount |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Contact System | .018" (0.46 mm) diameter post |
Key Features
- Supports a maximum current rating of 3.2A per contact.
- Constructed with a liquid crystal polymer housing for high durability.
- Features gold-plated phosphor bronze contacts to ensure excellent conductivity and corrosion resistance.
- Designed with two rows and straight orientation for versatile mounting options.
- Shrouded body supports blind mating applications.
- Termination is by solder type through-hole mount for secure PCB attachment.
- Operates reliably between -55°C and 125°C temperature range.
- Rated for 250V voltage operation in demanding electronic environments.
Product Description
Samtec TFM-104-01-L-D-WT Straight Through Hole PCB Header is a high-reliability connector designed for electronic components requiring robust wire-to-board connections. This model features 8 gold-plated phosphor bronze contacts arranged in 2 rows with a 1.27 mm pitch. The shrouded design enhances mating reliability, suitable for high cycle and harsh environments.
Housed in liquid crystal polymer, the connector ensures durability and stability under varying industrial conditions. It supports a current rating of 3.2A per contact and withstands operating temperatures from -55°C to 125°C, making it suitable for applications in electronics manufacturing, industrial control systems, and instrumentation.
The termination type is solder through-hole mounting, providing secure mechanical and electrical connections to printed circuit boards. Its straight orientation facilitates flexible PCB layouts, while multiple specialized features like screw down, weld tab, and solder nail expand its application scope, including rugged and harsh environment uses.
The 250V rating ensures safe operation in typical power and signal applications. This connector series, bearing the Tiger Eye™ contact system, is known for extended life and high-cycle durability, ideal for professional and industrial usage.
Supports 3.2A current per contact for robust signal integrity. Liquid crystal polymer housing for enhanced durability and heat resistance. Gold-plated phosphor bronze contacts provide excellent conductivity and corrosion resistance.
Shrouded body improves blind mating capability and protection. Dual-row, 1.27 mm pitch configuration suits standard PCB layouts. Solder termination through-hole mounting secures mechanical fit. Operates across wide temperature range (-55°C to 125°C) for industrial applications.
Includes rugged mounting options such as screw down and weld tabs. It is part of the PCB Header category in the EnvMart industrial catalog, providing reliable and efficient electrical connections in high-demand environments.
Explore our extensive catalog of electronic components and PCB accessories at EnvMart for compatible connectors, sockets, and assembly tools.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this model is 3.2A per contact.
This PCB header is rated for 250V voltage operation.
The housing is constructed from liquid crystal polymer, which provides enhanced durability and heat resistance.
This model features 8 contacts arranged in 2 rows.
It uses a solder termination type for through-hole mounting.
The contacts are arranged with a pitch of 1.27 mm.
It operates reliably between -55°C and 125°C.
It includes screw down, weld tab, and solder nail options for rugged requirements.
This connector supports wire-to-board connections, suitable for various electronic applications.
The contacts are made of gold-plated phosphor bronze, ensuring excellent conductivity and corrosion resistance.
Yes, the shrouded design and rugged materials make it suitable for high cycle and harsh environments.
The country of origin for this PCB header is India.
