Samtec Right Angle Through Hole PCB Header 40 Contacts 2.54 mm Pitch 2 Row Shrouded IPL1

Samtec IPL1 is a right angle through hole PCB header designed for high-performance electronic component assemblies. Featuring 40 individual contacts arranged in 2 rows with a pitch of 2.54 mm, this shrouded header provides secure wire-to-board connectivity with reliable mechanical strength and electrical performance.

The housing utilizes Liquid Crystal Polymer, which offers excellent durability and resistance to high operating temperatures ranging from -55°C to 125°C. Contacts are made from phosphor bronze and plated with gold ensuring superior conductivity and corrosion resistance, making it suitable for demanding industrial and commercial electronics.

This header supports a voltage rating up to 954 V and a current carrying capacity of up to 3.8 A at 95°C, making it ideal for a variety of power and signal transmission applications in PCB design. Its solder tail termination with 1.52 mm tail pin length facilitates robust soldering to the PCB, assuring long-term reliability.

The right-angle orientation optimizes PCB space and routing, while the shrouded contact design protects against accidental shorts and enhances connector mating alignment. The male contact gender and through hole mount type suit multiple assembly configurations demanding strong mechanical retention.

Industrial uses include electronic manufacturing, automation control systems, instrumentation, and telecommunications equipment. It is compatible with design software tools for easy incorporation into PCB layouts, and comes with comprehensive technical documentation including RoHS compliance certificates.

Designed for through hole mount ensuring strong mechanical PCB fixation. Phosphor bronze contacts with gold plating for enhanced conductivity and corrosion resistance. Durable Liquid Crystal Polymer housing material suitable for harsh environments.

Operating temperature range from -55°C to 125°C covering extreme conditions. Supports 954 V voltage rating and 3.8 A current rating at 95°C. Right angle orientation optimizes space and wiring on PCB. Shrouded contacts enhance electrical safety and connector alignment.

Solder tail termination with 1.52 mm pin length for reliable assembly. Male contact gender compatible with wire-to-board connector systems. Explore the wide range of PCB Headers at EnvMart for your electronics design and manufacturing needs.
