Samtec TSW Series Straight Through Hole Pin Header, 16 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSW-116-05-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.3A |
| Model | TSW-116-05-T-S |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.3mm |
| Mating Pin Length | 2.67mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed with phosphor bronze contacts ensuring durability and conductivity.
- Contact plating is tin for effective soldering and corrosion resistance.
- Suitable for board-to-board connection with a single row configuration.
- Unshrouded design allowing easy access to contacts.
- Operates reliably between -55°C and 105°C temperature range.
- Rated for 550V operating voltage and 4.3A maximum current capacity.
- Features tail pin length of 3.3 mm and mating pin length of 2.67 mm for secure connection.
- Ideal for industrial electronic component applications requiring robust PCB connectors.
Product Description
Samtec TSW-116-05-T-S is a straight through-hole pin header designed for PCB connectivity, featuring 16 phosphor bronze contacts with tin plating for optimal conductivity and solderability. Its 2.54 mm pitch and single row configuration make it versatile for board-to-board applications.
The pin header supports an operating voltage of 550V and a current rating of 4.3A, performing reliably within a temperature range of -55°C to 105°C. The unshrouded contact system facilitates straightforward access, while the tail pin length of 3.3 mm and mating pin length of 2.67 mm ensure secure and stable mating.
Constructed with polybutylene terephthalate housing, it provides excellent mechanical strength and electrical insulation. This connector is particularly suited for various industrial electronics, power, and control systems requiring durable and precise PCB connections.
Constructed with phosphor bronze contacts ensuring durability and conductivity. Contact plating is tin for effective soldering and corrosion resistance. Suitable for board-to-board connection with a single row configuration.
Unshrouded design allowing easy access to contacts. Operates reliably between -55°C and 105°C temperature range. Rated for 550V operating voltage and 4.3A maximum current capacity. Features tail pin length of 3.3 mm and mating pin length of 2.67 mm for secure connection.
Ideal for industrial electronic component applications requiring robust PCB connectors. No special certifications but designed with multiple plating and ruggedizing options.
This pin header is part of the renowned Samtec TSW series, known for its broad variety of pin counts, terminal lengths, and customizable features that optimize cost and performance for industrial electronics manufacturing.
Explore more PCB Headers and electronic components at EnvMart for high-quality industrial-grade connectors suitable for laboratory, manufacturing, and commercial electronic applications.
