Samtec Pin Header 20 Contacts 2.54 mm Pitch 1 Row Unshrouded Through Hole TSW-120-07-G-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.3A |
| Model | TSW-120-07-G-S |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.54mm |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed with Polybutylene Terephthalate housing for durability.
- Phosphor Bronze contacts plated in gold providing excellent conductivity.
- Rated for continuous current up to 4.3 A with voltage rating of 550 V.
- Operating temperature range from -55° C to 125° C.
- Male straight orientation, designed for board-to-board applications.
- Pin lengths include tail pins of 2.54 mm and mating pins of 5.84 mm.
- Termination type is solder through-hole for secure PCB connection.
- No shrouding allows versatile connectivity in various electronic assemblies.
Product Description
Samtec TSW-120-07-G-S pin header is a high-quality electronic connector designed for precise board-to-board interconnection with a 2.54 mm (0.100") pitch. It features 20 straight male contacts arranged in a single row, making it ideal for applications requiring compact yet reliable connections.
The housing is made from robust Polybutylene Terephthalate, ensuring excellent mechanical strength and resistance to environmental factors. Phosphor Bronze contacts with gold plating provide low electrical resistance and reliable conductivity over extended use.
This pin header supports continuous currents up to 4.3 A and withstands voltages up to 550 V, allowing its use in demanding industrial, commercial, and electronic manufacturing environments.
Operating temperature range from -55° C to 125° C enables stable performance across a broad range of conditions. The component is designed for through-hole solder termination, assuring solid mechanical retention on printed circuit boards.
Polybutylene Terephthalate housing material ensures durability. Gold-plated phosphor bronze contacts optimize conductivity and corrosion resistance. Single row straight male orientation supports diverse connector system needs.
2.54 mm pitch and 20 contact points offer standardized spacing for compatibility. Designed for board-to-board mounting providing efficient electrical interconnection. Wide operating temperature range from -55° C to 125° C offers reliability in harsh environments.
Pin lengths include 2.54 mm tail pins and 5.84 mm mating pins for secure connections. Unshrouded design maximizes accessibility and flexibility.
Ideal for industries including industrial electronics, laboratory instrumentation, telecommunications, and construction electronics, this pin header meets exacting standards for performance and durability.
Explore the full range of PCB connectors and headers at EnvMart for compatible accessories and related components.
Explore more products in our PCB Pin Header category.
