Samtec TSM Series Straight Surface Pin Header 10 Contact 2.54 mm Pitch 1 Row Unshrouded TSM-110-01-S-SV
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4A |
| Model | TSM-110-01-S-SV |
| Mount Type | Surface |
| Special Features | Designed specifically for surface mount applications with many options to facilitate processing |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination | Surface mount, mixed technology |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Rated for 4 amps current capacity ensuring reliable electrical performance.
- Constructed with a Liquid Crystal Polymer housing for durability and stability.
- Phosphor Bronze male contacts plated with gold for optimal conductivity and corrosion resistance.
- Designed for surface mount termination with solder type and mixed technology compatibility.
- Operating temperature range from -55°C to 125°C suitable for harsh industrial environments.
- Contact mating pin length of 5.84 mm facilitating secure mating connections.
- Unshrouded, straight orientation suitable for board-to-board connectivity.
- Designed specifically for surface mount applications with multiple options to facilitate processing.
Product Description
Samtec TSM-110-01-S-SV is a high-performance straight surface mount pin header designed for electronic circuit board applications requiring robust and reliable connections. This component features 10 phosphor bronze male contacts plated with gold to ensure enhanced conductivity and resistance to corrosion. The housing is made from Liquid Crystal Polymer, providing excellent durability and thermal stability for intensive industrial and commercial use.
Operating within a temperature range of -55°C to 125°C and rated for 4 amps current and 475 volts voltage, it is suitable for demanding electronic environments. The pin header features a standard 2.54 mm pitch and 1 row configuration, making it compatible with a wide range of printed circuit boards.
The unshrouded design and 5.84 mm mating pin length allow for flexible board-to-board connections, particularly in surface mount technology applications where space and processing efficiency are essential. Termination is via solder and supports mixed technology assemblies.
This pin header series is ideal for use in industrial electronics, telecommunications, computing hardware, and other applications requiring reliable electrical connectors. Its design facilitates easy processing and integration within complex PCB assemblies.
Rated for 4 amps current capacity ensuring reliable electrical performance. Constructed with a Liquid Crystal Polymer housing for durability and stability. Phosphor Bronze male contacts plated with gold for optimal conductivity and corrosion resistance.
Designed for surface mount termination with solder type and mixed technology compatibility. Operating temperature range from -55°C to 125°C suitable for harsh industrial environments. Voltage rating of 475V supporting high voltage applications in electronics.
Contact mating pin length of 5.84 mm facilitating secure mating connections. Unshrouded, straight orientation suitable for board-to-board connectivity. Designed specifically for surface mount applications with multiple options to facilitate processing.
Choose Samtec TSM series pin headers for dependable connectivity solutions in electronics manufacturing and assembly. Explore more PCB Headers and connectors in the Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current capacity of 4 amps, ensuring reliable electrical performance.
The voltage rating of the TSM-110-01-S-SV is 475 volts, making it suitable for high voltage applications in electronics.
It operates within a temperature range of -55°C to 125°C, suitable for harsh industrial environments.
The housing is made from Liquid Crystal Polymer, while the male contacts are phosphor bronze plated with gold for optimal conductivity and corrosion resistance.
This model features 10 contacts, designed for effective board-to-board connectivity.
The pitch size for this pin header is 2.54 mm, which is standard for many PCB applications.
It is designed for surface mount termination and supports mixed technology assemblies with solder type connections.
The contact mating pin length is 5.84 mm, facilitating secure mating connections.
The TSM-110-01-S-SV has a straight orientation, which is suitable for board-to-board connectivity.
This model is unshrouded, allowing for flexible connections in surface mount applications.
The country of origin for this pin header is the United States.
It is ideal for use in industrial electronics, telecommunications, and computing hardware, requiring reliable electrical connectors.
