Samtec SSW Series Straight Through Hole PCB Socket, 2-Contact, 1 Row, 2.54 mm Pitch Solder SSW-102-01-S-S

Free Delivery in India | Lowest Global Shipping Charges

Samtec SSW Series Straight Through Hole PCB Socket, 2-Contact, 1 Row, 2.54 mm Pitch Solder SSW-102-01-S-S

Name: Samtec SSW Series Straight Through Hole PCB Socket, 2-Contact, 1 Row, 2.54 mm Pitch Solder SSW-102-01-S-S
Brand: Samtec
SKU: 154508
Price: 1.02 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	655V
Brand	Samtec
Orientation	Straight
Current	4.7A
Model	SSW-102-01-S-S
Mount Type	Through Hole
Special Features	Standard and low insertion force contacts with standard solder tails
Housing Material	Liquid Crystal Polymer
Contact Material	Bronze
Series	SSW
Termination	Through-hole, surface mount
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Socket Strip
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	2
Contact Gender	Female
Connector System	Board-to-Board
Contact System	Tiger Buy™

Key Features

Features a liquid crystal polymer housing for high durability.
Operates at voltage up to 655V and current rating of 4.7A.
Contact material is bronze with gold plating ensuring reliable conductivity.
Suitable for operating temperatures from -55°C to 125°C.
Includes Tiger Buy™ contact system for secure and cost-effective connection.
Termination types include both through-hole and surface mount options.
Designed with female contact gender and straight orientation for vertical mounting.
Special features include standard and low insertion force contacts with standard solder tails.

Product Description

Samtec SSW-102-01-S-S PCB Socket is a high-quality straight through hole connector designed with a 2-contact, single-row configuration featuring a 2.54 mm pitch solder termination. This socket is crafted with a durable liquid crystal polymer housing material for enhanced mechanical and thermal stability, suited for demanding electronic and electrical applications.

It supports a maximum current rating of 4.7A and a voltage rating of 655V, making it suitable for various board-to-board connector systems. The bronze contacts plated with gold provide excellent conductivity and resistance to corrosion, which is critical for maintaining signal integrity in industrial, commercial, and electronics manufacturing environments.

This PCB socket is engineered to operate reliably within a temperature range of -55°C to 125°C, permitting its use in harsh environments and temperature-sensitive applications including industrial control systems, communication equipment, and automated assemblies. The contact system utilizes Samtec's Tiger Buy™ technology, known for high retention forces and cost-effectiveness.

The termination options provide flexibility with both through-hole and surface mount types available, allowing adaptation to different PCB assembly processes. Its female contact gender with a straight orientation facilitates vertical mounting and ensures compatibility with standard square post terminals.

Liquid crystal polymer housing for mechanical strength. Tiger Buy™ contact system for secure electrical connection. Gold-plated bronze contacts for durability and conductivity. Rated for 655V and 4.7A operational use. Wide operating temperature from -55°C to 125°C.

Suitable for board-to-board connector systems. Termination types include through-hole and surface mount. Standard and low insertion force contact options for ease of assembly. Applicable in industrial, laboratory, manufacturing, and electronic assembly applications.

This Samtec PCB socket is an ideal component for designers and OEMs aiming for reliable, high-performance electrical connections in complex PCB layouts. Explore more PCB Sockets and connectors on EnvMart for diverse industrial and commercial applications.
