Samtec PCB Socket Right Angle Surface Mount 10-Contact 2 Row 1.27 mm Pitch CLP-105-02-F-D-A
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 395V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 3.4A |
| Model | CLP-105-02-F-D-A |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | CLP |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Connector System | Board-to-Board |
Key Features
- Features a dual row, 10-contact configuration ensuring reliable board-to-board connection.
- Constructed with liquid crystal polymer housing for high durability and thermal stability.
- Gold-plated bronze contacts provide excellent conductivity and corrosion resistance.
- Designed for surface mount applications with right angle orientation for space-saving layouts.
- Rated for 395V voltage and 3.4A current, suitable for industrial electronic circuits.
- Operating temperature range from -55°C to 125°C supports harsh environments.
- Termination by solder method ensures secure and lasting electrical contact.
- Produced under the CLP series with no certifications specified.
Product Description
Samtec CLP-105-02-F-D-A is a right angle surface mount PCB socket designed for board-to-board connector systems, featuring 10 contacts arranged in 2 rows with a 1.27 mm pitch. This socket is constructed with liquid crystal polymer housing, providing excellent durability and thermal resistance, ideal for industrial, electronic component, and manufacturing applications.
The contacts are made of bronze and plated with gold to ensure high conductivity and reliable, corrosion-resistant electrical connections. Featuring a surface mount termination type, this socket fits well in tight PCB layouts requiring a low profile, right angle connection.
It is rated for a maximum voltage of 395V and a current of 3.4A, supporting robust electrical performance across a wide temperature range of -55°C to +125°C, making it suited for demanding environments in electronics manufacturing and industrial machinery.
This product is manufactured in the United States and belongs to Samtec's CLP series, which emphasizes quality and extended product life. It is intended for use in electronic assemblies requiring secure and efficient board-to-board connections.
Dual-row, 10-contact right angle configuration provides efficient PCB interconnections. Liquid crystal polymer housing offers thermal stability and mechanical strength. Bronze contact with gold plating ensures excellent conductivity and corrosion resistance.
Surface mount termination supports compact PCB designs. Voltage rating of 395V and current rating of 3.4A accommodate industrial applications. Operational temperature range from -55°C to 125°C for reliability in harsh conditions.
Manufactured in the United States ensuring strict quality controls.
Suitable for electronic component manufacturing, industrial electronics, and assembly operations, the Samtec CLP-105-02-F-D-A PCB socket provides a high-quality, durable connection solution. For more products in PCB Sockets and related components, explore EnvMart’s extensive catalog.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this model is 395V.
This PCB socket has a current rating of 3.4A.
The contacts in this socket are arranged with a pitch of 1.27 mm.
The housing is constructed from liquid crystal polymer, providing thermal stability and mechanical strength.
This PCB socket features a total of 10 contacts arranged in 2 rows.
The operational temperature range for this model is from -55°C to +125°C.
This model uses solder termination for secure electrical connections.
The orientation of this PCB socket is right angle, which is suitable for space-saving layouts.
The contacts are made of bronze and are gold-plated to ensure excellent conductivity and corrosion resistance.
This product is manufactured in the United States.
This PCB socket is part of a board-to-board connector system.
It is suitable for electronic component manufacturing, industrial electronics, and assembly operations.
