JST SUR Series Right Angle PCB Header 4 Contacts 0.8 mm Pitch 1 Row Shrouded SM04B-SURS-TF (LF)(SN)

JST SM04B-SURS-TF (LF)(SN) Right Angle PCB Header is a high-precision connector designed for electronic applications requiring compact wire-to-board connections. With 4 contacts arranged in a single row at 0.8 mm pitch, this shrouded header minimizes space on PCBs while ensuring secure connections.

The housing is made of durable polyamide material, providing excellent electrical insulation and mechanical durability necessary for demanding electronics environments. Copper alloy contacts with copper plating ensure excellent conductivity and corrosion resistance, supporting a voltage rating of 30V and continuous current of 200mA.

This right angle connector features a solder termination type with male contact pins each having a tail length of 0.45 mm. Operating reliably within a temperature range of -25°C to 85°C, it is suitable for various commercial and industrial electronics assemblies.

The compact design reduces PCB occupation area by approximately 34% compared to standard 1.0 mm pitch connectors, making it ideal for space-critical applications such as communication devices, instrumentation, and consumer electronics.

Its shrouded construction provides enhanced protection to the connector interface, reducing the risk of damage and improving longevity. The wire-to-board connector system ensures stable mechanical and electrical performance.

Features a 0.8 mm pitch enabling space-saving on PCB assemblies. Right angle orientation supports low profile PCB mounting. Shrouded header design enhances connector protection and durability. Constructed with polyamide housing for robust insulation properties.

Contacts made of copper alloy with copper plating ensure reliable conductivity. Electrical rating up to 30V and 200mA current capacity. Suitable for solder termination and includes male contact gender pins. Operates reliably between -25°C and 85°C under normal conditions.

Compact dimensions reduce board footprint by approximately 34% compared to conventional 1.0 mm pitch connectors. Manufactured in Malaysia adhering to high production standards.

This PCB header is ideal for industrial, telecommunications, consumer electronics, and laboratory equipment assembly requiring precise and dependable board interconnections. Explore more PCB connectors and accessories at EnvMart to complete your electronic setup.
