Hirose A3B Series Straight Through Hole Pin Header, 32 Contacts, 2 mm Pitch, 2 Row, Unshrouded A3B-32PA-2DSA(51)
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 200V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 1A |
| Model | A3B-32PA-2DSA(51) |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Brass |
| Series | A3B |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 32 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.6mm |
| Mating Pin Length | 3.5mm |
| Miniature Type and High Density Mounting | These connectors are designed in a miniature and light weight product, and mounted in the high density. The crimping case is structured in the 2mm pitch grid, so that connectors can be arranged for use |
| Variation in Number of Contacts | In addition to the dip type, SMT and crimping types are available with broad variations |
| Stacking Variation | When the connector is used for board to board, set 6mm between boards in conjunction with the pin header A3B, or 5.1mm between boards in conjunction with the pin header A3C |
Key Features
- The connector supports a current rating of 1 ampere for reliable electronic applications.
- Constructed with polyamide housing and brass contacts plated with gold for enhanced durability and corrosion resistance.
- Solder termination type with male contact gender and a tail pin length of 2.6 mm for secure mounting.
- Operates within a temperature range from -55°C to 85°C, suitable for diverse environmental conditions.
- Designed for wire-to-board connection with through hole mount type and 200 V voltage rating.
- Complies with RoHS standards, ensuring environmentally friendly manufacturing.
- Ideal for high-density PCB mounting and board-to-board applications with specific stacking variations.
- The 2 mm pitch and two-row construction enable compact and space-saving PCB designs.
Product Description
Hirose A3B-32PA-2DSA(51) Pin Header is a miniature, high-density connector designed for electronic components requiring compact and reliable wire-to-board connection solutions. Featuring 32 contacts arranged in 2 rows with a 2 mm pitch, this unshrouded straight through hole pin header supports current up to 1 ampere and voltage up to 200 V.
The connector's polyamide housing offers lightweight yet robust protection, while the brass contacts plated with gold ensure excellent electrical conductivity and corrosion resistance. With a solder termination type and male contact gender, mounting is secure, aided by a tail pin length of 2.6 mm and a mating pin length of 3.5 mm.
The product operates efficiently in temperatures ranging from -55°C to 85°C, making it suitable for industrial, electronic manufacturing, communication equipment, and laboratory applications. Its RoHS compliance guarantees adherence to environmental safety standards.
Hirose's A3B series pin header supports stacking variations for board-to-board mounting, allowing a 6 mm space between boards when used with the A3B pin header or 5.1 mm with the A3C variation, enabling flexible design configurations.
The connector is ideal for high-density PCB mounting requirements in electronics manufacturing. Its superior materials and plating provide durability and signal integrity in harsh operating environments. The 2 mm pitch and two-row construction enable compact and space-saving PCB designs.
Straight orientation and through hole mount ensure easy installation and robust mechanical stability. The design allows for versatile usage in wire-to-board connector systems across various electronic devices.
This Hirose pin header, made in Japan, embodies quality and precision engineering. For more components like this, browse our PCB Pin Headers category on EnvMart, your destination for certified industrial electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 1 ampere, making it suitable for reliable electronic applications.
The pin header has a voltage rating of 200 V, allowing it to be used in various electronic applications.
It features a polyamide housing and brass contacts plated with gold, enhancing durability and corrosion resistance.
This connector operates efficiently within a temperature range of -55°C to 85°C, suitable for diverse environmental conditions.
The Hirose A3B-32PA-2DSA(51) features 32 contacts arranged in 2 rows.
It utilizes a solder termination type, ensuring a secure and stable connection.
The tail pin length is 2.6 mm, which aids in secure mounting on printed circuit boards.
The contacts are arranged with a pitch of 2 mm, allowing for compact PCB designs.
Yes, the Hirose A3B-32PA-2DSA(51) complies with RoHS standards, ensuring environmentally friendly manufacturing.
This model has a straight orientation, which facilitates easy installation.
Yes, it supports stacking variations for board-to-board mounting, allowing a 6 mm space between boards when used with the A3B pin header.
This connector is manufactured in Japan, reflecting quality and precision engineering.
