Artesyn / Advanced Energy DC/DC Converter 15V DC Output 5A 66-160V DC Input 75W Through Hole Package ERM75

Artesyn / Advanced Energy presents the ERM75 series DC/DC Converter model ERM75 delivering a stable 15V DC output with a current capacity of 5A. It accepts a wide DC input range from 66V to 160V, making it suitable for demanding railway and rolling stock power applications.

This converter features a high-efficiency design at 91%, minimizing energy loss and heat generation. Built into a compact through hole DIP package measuring 57.9 mm in length, 36.8 mm in width, and 12.7 mm in depth, it supports easy integration into various electronic assemblies.

With reinforced 1.5 kV DC isolation, the unit ensures electrical safety and compliance with industry isolation standards. The device operates reliably across a temperature range of -40°C to 70°C. The fully encapsulated metal casing includes an isolated baseplate that enhances thermal management and mechanical protection.

The ERM75 has a mean time between failure (MTBF) rating of 209,000 hours, indicating high reliability for industrial use. Additional features include under-voltage shutdown to protect the system and a remote On/Off control function for operational flexibility.

Designed primarily for railway and rolling stock applications. Compact quarter-brick footprint measuring 57.9 x 36.8 x 12.7 mm. High efficiency of approximately 91% for energy saving. Single output with reinforced isolation at 1.5 kV DC.

Wide operating temperature range from -40 °C to 70 °C. Fully encapsulated metal case with isolated baseplate for durability and safety. Includes under-voltage shutdown and remote On/Off control features. MTBF rated at 209,000 hours ensures reliability.

Industry standard through-hole DIP package type.

This DC/DC converter is ideal for industrial electronics, railway transport power supplies, manufacturing equipment, and other applications requiring stable voltage conversion under harsh conditions.
