Nexperia 10 V Zener Diode Single 250 mW 5% Surface Mount 3-Pin SOT-23 BZX84-C10,235

Name: Nexperia 10 V Zener Diode Single 250 mW 5% Surface Mount 3-Pin SOT-23 BZX84-C10,235
Brand: Nexperia
SKU: 150396
Price: 0.03 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.1mm
Length	3mm
Model	BZX84-C10,235
Mount Type	Surface
Series	BZX84
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	250mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	200nA
Nominal Zener Voltage Vz	10V
Zener Type	Voltage Regulator
Maximum Zener Impedance	20Ω
Typical Voltage Temperature Coefficient	6.4mV/K
onsemi 1, 10 V Zener Diode, Single 300 mW 6 % Surface 3-Pin SOT-23Brand	onsemi

Key Features

Nominal Zener voltage of 10 V ensures stable voltage reference.
Maximum power dissipation of 250 mW suitable for low power applications.
5% voltage tolerance provides consistent performance.
Compact SOT-23 package supports surface mounting for high-density circuit boards.
Maximum operating temperature up to 150°C allows use in demanding environments.
Low maximum reverse leakage current of 200 nA minimizes power loss.
Typical voltage temperature coefficient of 6.4 mV/K ensures predictable behavior over temperature.
Meets automotive standard AEC-Q101 for enhanced quality assurance.

Product Description

Nexperia BZX84-C10,235 is a high-quality 10 V Zener Diode designed for voltage regulation in electronic circuits. It is housed in a compact 3-pin SOT-23 surface-mount package, making it suitable for high-density PCB layouts and various low-power applications. With a maximum power dissipation of 250 mW and a 5% voltage tolerance, it delivers precise voltage regulation and over-voltage protection in a small footprint.

The diode supports a maximum operating temperature of 150°C and a minimum temperature as low as -65°C, ensuring durability in a wide range of environmental conditions. Low maximum reverse leakage current of 200 nA allows energy-efficient operation, while the typical voltage temperature coefficient of 6.4 mV/K ensures stable voltage performance across temperature variations.

This device complies with the automotive AEC-Q101 standard, reflecting its reliability and suitability for automotive and industrial electronic applications. The BZX84 series includes 37 breakdown voltages between 2.4 V and 75 V, offering versatile options for design needs.

Nominal Zener voltage: 10 V with ±5% tolerance. Maximum power dissipation: 250 mW. Package: SOT-23 3-pin surface mount. Test current: 5 mA. Maximum Zener impedance: 20 Ω. Operating temperature range: -65°C to 150°C. Maximum reverse leakage current: 200 nA.

Typical voltage temperature coefficient: 6.4 mV/K. Automotive grade AEC-Q101 certification.

This Zener diode is ideal for providing voltage regulation, over-voltage protection, and voltage reference in industrial, automotive, and electronic manufacturing applications. Its reliable performance in a space-saving SMD package makes it a preferred choice for engineers designing high-density and compact printed circuit boards.
