TE Connectivity MULTIGIG RT 2 1.8 mm Pitch VITA 46 Centre Backplane Connector, Straight Female, 16 Column, 9 Row 1410140-1

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity MULTIGIG RT 2 1.8 mm Pitch VITA 46 Centre Backplane Connector, Straight Female, 16 Column, 9 Row 1410140-1

Name: TE Connectivity MULTIGIG RT 2 1.8 mm Pitch VITA 46 Centre Backplane Connector, Straight Female, 16 Column, 9 Row 1410140-1
Brand: TE Connectivity
SKU: 148417
Price: 66.14 USD
Availability: InStock



Category Backplane Connectors Brand TE Connectivity Condition New

Specifications

Country of Origin	United States
Brand	TE Connectivity
Orientation	Straight
Current	1A
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	MULTIGIG RT 2
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	9
Number of columns	16
Pitch	1.8mm
Contact Plating	Gold over Nickel
Number of Contacts	144
Contact Gender	Female
Connector Gender	Female
Backplane Connector Type	VITA 46 Centre

Key Features

Features 144 female contacts arranged in 16 columns and 9 rows.
Constructed with liquid crystal polymer housing for durability.
Phosphor bronze contacts plated with gold over nickel for superior conductivity.
Supports current rating of 1A with solder termination and through-hole mount type.
Operates reliably in temperatures ranging from -55°C to 105°C.
Compliant with VITA 46 VPX standards for high-speed data rates exceeding 10 Gbit/s.
Pinless interface enhances durability and reduces risk of mis-mating.
Optimized modular design ensures improved signal integrity and reduced crosstalk.

Product Description

TE Connectivity 1410140-1 MULTIGIG RT 2 1.8 mm Pitch VITA 46 Centre Backplane Connector is a precision-engineered high-speed female connector designed for advanced backplane applications. It features 144 contacts arranged in a 16-column by 9-row grid with a straight orientation and through-hole mount style.

The connector housing is made of liquid crystal polymer, offering excellent mechanical stability and electrical insulation. Contacts are made from phosphor bronze and plated with gold over nickel to ensure reliable conductivity and corrosion resistance.

This MULTIGIG RT 2 backplane connector complies with VITA 46 VPX standards, supporting data transmission rates exceeding 10 Gbit/s, critical for modern high-bandwidth military, aerospace, and telecommunications systems. The pinless interface design enhances reliability by eliminating traditional pins, which reduces wear and misalignment during mating cycles.

Operating temperature ranges from -55°C to 105°C making this connector suitable for harsh environmental conditions. It is rated for 1A current and uses solder termination with through-hole mounting to ensure sturdy PCB connections.

Features 144 female contacts arranged in 16 columns and 9 rows. Constructed with liquid crystal polymer housing for high mechanical and thermal performance. Phosphor bronze contacts with gold over nickel plating for excellent electrical conductivity.

Pinless interface reduces risk of damage and improves durability. Supports high-speed data rates over 10 Gbit/s compliant with VITA 46 VPX standards. Optimized modular footprint for superior signal integrity and reduced crosstalk.

Polarization keys prevent incorrect mating ensuring reliable connections. Suitable for military, aerospace, defense, telecom, data storage, and rugged industrial applications. Its robust construction and versatile modular design allows customization and flexibility for various backplane configurations.
