Samtec BCS Series Straight Through Hole PCB Socket, 30-Contact, 2 Row, 2.54 mm Pitch, Solder Termination BCS-115-L-D-PE
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.6A |
| Model | BCS-115-L-D-PE |
| Mount Type | Through Hole |
| Special Features | Top and bottom entry pass-through options |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | BCS |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 30 |
| Connector System | Board-to-Board |
| Contact System | Tiger Claw™ |
Key Features
- Supports board-to-board connection with 2 rows and 30 contacts.
- Rated at 4.6A current capacity for reliable performance.
- Pitch measures 2.54 mm for standard pin spacing.
- Housing made of liquid crystal polymer ensuring durability and heat resistance.
- Contact material is bronze with gold plating to enhance conductivity and corrosion resistance.
- Operates reliably within temperature range of -55°C to 125°C.
- Through hole mount type for secure PCB installation.
- Features Tiger Claw™ contact system for enhanced connection stability.
Product Description
Samtec BCS-115-L-D-PE is a straight through hole PCB socket connector from the BCS series, designed for board-to-board electronic connections. This connector features 30 contacts arranged in 2 rows with a standard 2.54 mm pitch and solder termination type, making it suitable for through-hole PCB mounting.
The housing is crafted from high-quality liquid crystal polymer, providing excellent durability and thermal stability. Contacts are made of bronze with a gold plating, ensuring superior electrical conductivity and resistance to corrosion. The connector supports currents up to 4.6A and operates safely at voltages up to 475V, with an operating temperature range from -55°C to 125°C.
Utilizing the Tiger Claw™ contact system, this PCB socket ensures secure and reliable connections with top and bottom entry pass-through options for versatile PCB layout options. Its robust construction is ideal for demanding electronic, manufacturing, and industrial automation applications requiring stable board-to-board connections.
Supports board-to-board connection with 2 rows and 30 contacts. Rated at 4.6A current capacity for reliable performance. Pitch measures 2.54 mm for standard pin spacing. Housing made of liquid crystal polymer ensuring durability and heat resistance.
Contact material is bronze with gold plating to enhance conductivity and corrosion resistance. Operates reliably within temperature range of -55°C to 125°C. Through hole mount type for secure PCB installation. Voltage rating up to 475V suitable for various electronic applications.
Features Tiger Claw™ contact system for enhanced connection stability. Top and bottom entry pass-through options allow flexible design configurations.
This Samtec PCB socket is manufactured in the United States, meeting high quality standards and ensuring reliable performance across industrial, electronic manufacturing, and laboratory applications. It is a trusted choice for engineers requiring precision and durability in PCB connection systems.
Explore more PCB Sockets and connectors at EnvMart for your industrial and laboratory needs, featuring trusted brands and precise technical specifications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current capacity of 4.6A, ensuring reliable performance for board-to-board connections.
The voltage rating for this unit is up to 475V, making it suitable for various electronic applications.
The pitch size of the contacts is 2.54 mm, which is standard for many PCB applications.
The housing is made from liquid crystal polymer, while the contacts are constructed from bronze with gold plating for enhanced conductivity and corrosion resistance.
It operates reliably within a temperature range of -55°C to 125°C, allowing for use in various environments.
This PCB socket features 30 contacts arranged in 2 rows, facilitating efficient board-to-board connections.
It utilizes a through hole mount type, ensuring secure installation on the PCB.
It includes top and bottom entry pass-through options, providing flexibility in design configurations.
This model utilizes a board-to-board connector system, designed specifically for reliable electronic connections.
It features the Tiger Claw™ contact system, which enhances connection stability.
This PCB socket is manufactured in the United States, adhering to high quality standards.
The termination type is solder, which is standard for through-hole PCB mounting applications.
