Nexperia Zener Diode 10 V 250 mW 5% Tolerance Surface-Mount 3-Pin SOT-23 BZX84-C10,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Zener Diode 10 V 250 mW 5% Tolerance Surface-Mount 3-Pin SOT-23 BZX84-C10,215

Name: Nexperia Zener Diode 10 V 250 mW 5% Tolerance Surface-Mount 3-Pin SOT-23 BZX84-C10,215
Brand: Nexperia
SKU: 147647
Price: 0.03 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.1mm
Length	3mm
Model	BZX84-C10,215
Mount Type	Surface
Series	BZX84
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	250mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	200nA
Nominal Zener Voltage Vz	10V
Zener Type	Voltage Regulator
Maximum Zener Impedance	15Ω
Typical Voltage Temperature Coefficient	6.4mV/K
onsemi 1, 10 V Zener Diode, Single 300 mW 6 % Surface 3-Pin SOT-23Brand	onsemi

Key Features

This diode features a compact 3-pin SOT-23 package for high-density circuit designs.
Maximum power dissipation is rated at 250 mW suitable for low power applications.
Nominal Zener voltage is 10 volts with a tolerance of ±5% to maintain voltage stability.
Operating temperature ranges from -65°C to 150°C ensuring reliable performance in varied environments.
The diode provides a maximum reverse leakage current of 200 nA and Zener impedance of 15Ω.
Complies with the automotive standard AEC-Q101 for high reliability in automotive circuits.
Typical voltage temperature coefficient is 6.4 mV/K for precise voltage regulation with temperature changes.
Ideal for use in voltage regulator, over-voltage protection, and general voltage reference applications.

Product Description

Nexperia BZX84-C10,215 is a 10 V Zener diode with a maximum power dissipation of 250 mW and a nominal voltage tolerance of ±5%. It comes in a compact 3-pin SOT-23 surface-mount package designed for use in low-power voltage regulator circuits.

The diode supports a maximum operating temperature of up to 150°C and a minimum of -65°C, suitable for automotive and industrial applications requiring reliable voltage regulation. It features a maximum reverse leakage current of 200 nA and a Zener impedance of 15Ω, providing stable voltage reference under varying load conditions.

Its AEC-Q101 automotive qualification ensures dependable performance for vehicle electronic systems. The typical voltage temperature coefficient of 6.4 mV/K allows for temperature-compensated voltage regulation. The diode's 3-pin package facilitates high-density circuit integration, making it suitable for compact PCB layouts.

Applications include over-voltage protection, general voltage reference, and voltage regulation in semiconductor circuits. This diode provides an economical alternative to integrated voltage regulators for compact electronic designs where space and power efficiency are critical.

This diode features a compact 3-pin SOT-23 package for high-density circuit designs. Maximum power dissipation is rated at 250 mW suitable for low power applications. Nominal Zener voltage is 10 volts with a tolerance of ±5% to maintain voltage stability.

Operating temperature ranges from -65°C to 150°C ensuring reliable performance in varied environments. The diode provides a maximum reverse leakage current of 200 nA and Zener impedance of 15Ω. Complies with the automotive standard AEC-Q101 for high reliability in automotive circuits.

Typical voltage temperature coefficient is 6.4 mV/K for precise voltage regulation with temperature changes. Ideal for use in voltage regulator, over-voltage protection, and general voltage reference applications. Explore the Nexperia range and other semiconductor solutions at EnvMart for your electronic component needs.
