Hirose Connector Housing Male 12 Contacts 2 mm Pitch 2 Row Panel Mount Polyamide DF11

Hirose DF11-12DEP-2C is a male connector housing designed for 12 contacts arranged in 2 rows with a 2 mm pitch. This panel mount connector housing is constructed from durable polyamide material, combining compact size and reliable connection performance suitable for varied electronic applications.

The connector's compact double row design allows for space-efficient wiring configurations within a panel mount footprint measuring 19 mm in length and 13 mm in width, enabling high contact density with minimal depth less than 5 mm. Guide ribs are integrated to prevent mismating and twisting, while a friction locking mechanism secures the connection to mating sockets.

Mounting ears enable firm attachment to panels of 1.0 to 1.6 mm thickness, ensuring mechanical stability during operation and vibration.

This Hirose DF11 series connector housing is ideal for electronic devices that demand multiple signal paths within constrained spaces, including digital cameras, LCD displays, digital video recorders, car navigation systems, access control units, and measurement instruments.

Compact, space-saving double row configuration with 12 contacts. 2 mm pitch ensures precise and secure electrical connections. Male connector with panel mount type for stable installation. Made from durable polyamide material for long-lasting use.

19 mm length and 13 mm width provide a slim footprint. Guide ribs prevent incorrect mating and twisting during connection. Friction locking mechanism ensures secure connector engagement. Mounting ears allow firm retention on panels 1.0 to 1.6 mm thick.

Ideal for electronic equipment requiring multiple signals in limited space. Suitable for digital cameras, LCD displays, video recorders, and control units. Explore extensive electronic connector solutions including Hirose Connector Housings on EnvMart for your industrial and commercial applications.
