NVE 4-Channel Digital Isolator 110 Mbps, 2.5 kVrms Isolation, 5.5V Supply, 8-Pin SOIC IL716E

Free Delivery in India | Lowest Global Shipping Charges

NVE 4-Channel Digital Isolator 110 Mbps, 2.5 kVrms Isolation, 5.5V Supply, 8-Pin SOIC IL716E



Category Digital Isolator ICs Brand NVE Condition New

Specifications

Country of Origin	United States
Brand	NVE
Length	10.5mm
Model	IL716E
Depth	10.64mm
Width	2.67mm
Mount Type	Surface
Series	IL
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Maximum input current	6mA
Number Of Channels	4
Rise Time	4ns
Supply Voltage	5.5V
Standards/Approvals	IEC, UL
Maximum Forward Voltage	7V
Number of Pins	8
Maximum Data Rate	110Mbps
Propagation Delay Time	18ns
Package Style	SOIC

Key Features

Offers four independent digital isolation channels for signal integrity.
Supports a maximum data rate of 110 Mbps for fast communication.
Rated for isolation voltage of 2.5 kVrms for safety and reliability.
Operates with a supply voltage of 5.5 V for compatibility with industry standards.
Compact 8-pin SOIC surface-mount package for space-efficient PCB design.
Low propagation delay time of 18 ns ensures minimal signal latency.
Maximum forward voltage is 7 V, optimizing power efficiency.
Maximum input current of 6 mA supports low power consumption applications.

Product Description

The NVE IL716E is a high-speed, high-temperature 4-channel digital isolator designed for applications requiring robust signal isolation and integrity. This digital isolator IC supports data rates up to 110 Mbps and provides an isolation voltage of 2.5 kVrms, making it suitable for demanding industrial environments. Supplied in a small 8-pin SOIC surface mount package, the IL716E is ideal for space-constrained PCB layouts.

The device operates from a 5.5 V power supply and features very low propagation delay of just 18 ns, facilitating minimal signal latency essential for precise timing and synchronization in complex electronics. Its maximum forward voltage rating of 7 V and input current limited to 6 mA make it energy efficient, supporting low-power system designs.

The IL716E is rated for reliable performance over a wide temperature range from -40°C to 125°C, allowing it to withstand harsh industrial and automotive conditions. It meets IEC and UL standards, underlining its compliance to international safety and quality regulations. This product is engineered and manufactured in the United States, ensuring high quality and reliability.

Typical applications include industrial automation, motor control, data acquisition systems, and any scenario where robust, isolated digital data transmission is required to prevent ground loop issues and protect sensitive electronics.

Four independent digital isolator channels provide versatile connectivity. High maximum data rate ensures fast data communication. Robust isolation voltage safeguards electronics from high-voltage disturbances. Wide operating temperature supports use in extreme environments.

Meets critical safety standards for industrial and commercial applications.

EnvMart catalog offers a broad range of electronic components including Digital Isolator ICs such as the NVE IL716E for reliable industrial, laboratory, and commercial electronics applications.
