Skyworks Solutions Inc 6-Channel Digital Isolator 150 Mbps 3.75 kVrms 5.5V 16-Pin SOIC Si8660BC-B-IS1
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | Skyworks Solutions Inc |
| Length | 9.9mm |
| Model | Si8660BC-B-IS1 |
| Depth | 1.25mm |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | Si86 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Maximum input current | 12.3mA |
| Number Of Channels | 6 |
| Rise Time | 4ns |
| Power Dissipation | 415mW |
| Supply Voltage | 5.5V |
| Standards/Approvals | UL, CSA, IEC |
| Maximum Forward Voltage | 5.5V |
| Number of Pins | 16 |
| Automotive Standard | AEC-Q100 |
| Maximum Data Rate | 150Mbps |
| Propagation Delay Time | 13ns |
| Package Style | SOIC |
Key Features
- This isolator provides an isolation voltage of 3.75 kVrms ensuring high-voltage protection.
- Features a compact 16-Pin SOIC package suitable for surface mount applications.
- Operates at a maximum forward voltage of 5.5V with a power dissipation of 415 mW.
- Offers a low propagation delay time of 13 ns and rise time of 4 ns for fast switching performance.
- Supports an operating temperature range from -40°C up to 125°C.
- Designed and manufactured to automotive AEC-Q100 standards for high reliability.
- Includes 6 digital channels for versatile isolation solutions in electronic circuits.
- Has a maximum input current rating of 12.3 mA and operates at a supply voltage of 5.5V.
Product Description
The Skyworks Solutions Inc Si8660BC-B-IS1 digital isolator is a high-performance device designed for isolating digital signals in a wide range of electronic and industrial systems. Featuring six channels, this digital isolator utilizes advanced capacitive isolation technology to achieve low propagation delay and skew, low emissions, and high noise immunity, making it suitable for robust and reliable signal isolation across harsh environments.
Operating at a maximum data rate of 150 Mbps, the Si8660BC-B-IS1 supports communication with fast switching speeds, including a propagation delay of 13 nanoseconds and a rise time of 4 nanoseconds. Its isolation voltage of 3.75 kVrms ensures protection against high-voltage spikes and transients, safeguarding system components and improving overall system reliability.
Encased in a compact 16-pin SOIC package, this surface mount device measures 9.9 mm in length, 3.9 mm in width, and 1.25 mm in depth, facilitating easy integration into miniature circuits. It operates efficiently at a supply voltage of 5.5 V with low power dissipation of 415 mW and a maximum forward voltage of 5.5 V. The device is rated for operation over a wide temperature range from -40°C to 125°C, enabling use in demanding industrial and automotive conditions, meeting AEC-Q100 automotive standards.
The Si866x series, to which this model belongs, is known for its high reliability and long lifecycle advantage over traditional optocouplers, offering CMOS-based stable performance without lifespan limitations, lower power consumption, and reduced size and cost.
This device is particularly suited for applications in industrial automation, automotive electronics, power systems, and any environment requiring high-speed digital signal isolation with maximum safety.
The product's design complies with UL, CSA, and IEC standards, assuring quality and safety compliance.
This high-performance digital isolator enhances system efficiency and reliability, making it an essential component in modern electronic design. Explore more products in the Digital Isolator ICs category at EnvMart for a variety of advanced isolation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum data rate of 150 Mbps, allowing for fast digital signal communication.
It provides an isolation voltage of 3.75 kVrms, ensuring protection against high-voltage spikes.
The device measures 9.9 mm in length, 3.9 mm in width, and 1.25 mm in depth, making it suitable for surface mount applications.
It operates within a temperature range of -40°C to 125°C, suitable for various industrial and automotive conditions.
The power dissipation for this digital isolator is 415 mW, ensuring efficient operation.
The rise time is 4 ns, which contributes to its fast switching performance.
It complies with UL, CSA, and IEC standards, ensuring quality and safety compliance.
The maximum input current rating is 12.3 mA, which is important for ensuring proper operation.
It comes in a 16-pin SOIC package, designed for surface mount applications.
It is designed and manufactured to meet AEC-Q100 automotive standards, ensuring high reliability.
The propagation delay time is 13 ns, allowing for efficient signal transmission.
