Panasonic PCB Power Relay 12V DC Coil 10A Switching Current SPST ALQ3F12

Panasonic ALQ3F12 PCB Power Relay with a 12V DC coil and 10A switching current is engineered for reliable performance in electrical and industrial applications. Its compact size and robust design make it suitable for PCB mounting in diverse environments including industrial equipment, consumer appliances, and automation systems.

The relay features a single-pole single-throw (SPST) contact configuration allowing straightforward electrical switching. It operates effectively within a broad ambient temperature range of -40°C to +85°C, making it ideal for both harsh and moderate environments.

This ALQ series relay supports a switching power of 150W and can safely switch AC voltages up to 250V and DC voltages of up to 30V, thus facilitating efficient control of various electrical loads and circuits.

Equipped with a silver alloy contact material, it ensures minimal contact resistance of 100mΩ for reliable signal transmission and durability. The coil resistance of 720Ω with a power rating of 200mW allows efficient coil energizing with minimal power loss.

The relay meets critical safety and environmental standards including RoHS and VDE certification, guaranteeing quality assurance and compliance with industry norms.

Common applications include use in refrigerators, cooking ovens, washing machines, air conditioners, motor control systems, robots, and power supplies where compact size and reliable switching capacity are paramount.

Package includes one Panasonic ALQ3F12 PCB Power Relay. Ideal for industrial, commercial, and laboratory electrical projects requiring dependable power relay components. Explore more high-quality Power Relays and electrical components in EnvMart's extensive catalog for electronics and electrical automation solutions.

The relay supports a coil voltage of 12V DC ensuring reliable electromagnetic actuation. It features a single-pole single-throw (SPST) contact configuration suitable for various circuit switching applications. Compact dimensions with 20mm length, 15.6mm height, and 10mm width facilitate easy PCB mounting.

Wide operating temperature range from -40°C to 85°C supports use in harsh environments. High switching power of 150W enables control of moderate load applications efficiently. Coil resistance is precisely 720Ω with coil power consumption of 200mW for efficient operation.

Contact material uses silver alloy to ensure low contact resistance and enhanced durability. Designed to handle switching AC voltage up to 250V and DC voltage up to 30V safely. Meets RoHS compliance and VDE standards assuring quality and environmental safety.
