Microchip Complex Programmable Logic Device EEPROM 32 Cells, 32 I/O, 10 ns, 2 Logic Blocks, In-System ATF1502AS-10JU44

Free Delivery in India | Lowest Global Shipping Charges

Microchip Complex Programmable Logic Device EEPROM 32 Cells, 32 I/O, 10 ns, 2 Logic Blocks, In-System ATF1502AS-10JU44

Name: Microchip Complex Programmable Logic Device EEPROM 32 Cells, 32 I/O, 10 ns, 2 Logic Blocks, In-System ATF1502AS-10JU44
Brand: Microchip
SKU: 143506



Category Semiconductors Brand Microchip Condition New

Specifications

Country of Origin	Philippines
Brand	Microchip
Height	4.06mm
Length	16.66mm
Model	ATF1502AS-10JU44
Mount Type	Surface
Memory type	EEPROM
Series	ATF15xx
Maximum Operating Temperature	85°C
Package Type	PLCC
Minimum Operating Temperature	-40°C
Pin Count	44
Maximum Supply Voltage	5.25V
Minimum Supply Voltage	4.75V
Maximum Propagation Delay Time	10ns
Maximum Operating Frequency	125MHz
Number of Macro Cells	32
Number of User I/Os	32
Number of Logic Blocks/Elements	2

Key Features

Supports in-system programmability for flexible device updates.
Contains 32 macro cells and 32 general-purpose I/O pins.
Uses EEPROM memory technology for reliable logic storage.
Maximum propagation delay time is 10 nanoseconds for fast performance.
Packaged in a 44-pin PLCC surface mount package.
Operates over a voltage range of 4.75V to 5.25V.
Suitable for industrial temperature range from -40°C to 85°C.
Maximum operating frequency of 125 MHz for high-speed applications.

Product Description

Microchip ATF1502AS-10JU44 is a Complex Programmable Logic Device (CPLD) with 32 EEPROM cells and 32 user input/output pins, designed for in-system programmability. It features a maximum propagation delay time of 10 ns and contains 2 logic blocks, enabling reliable and flexible digital logic functions.

This device is encased in a 44-pin PLCC surface mount package suitable for space-efficient PCB assembly. The operating voltage ranges from 4.75V to 5.25V and it supports industrial temperature operation from -40°C to 85°C, making it well-suited for automotive and industrial electronics applications requiring robust performance and high-speed logic control.

The ATF1502AS-10JU44 supports individual output enable control, which enhances signal driving flexibility. It operates at a maximum frequency of 125 MHz allowing fast digital circuit responses in complex embedded systems.

As an EEPROM-based CPLD, it offers programmable logic that can be reprogrammed in-system, simplifying development cycles and updates to deployed hardware. This device is ideal for electronics designers and engineers working in industrial automation, embedded systems, and complex digital circuit prototyping.

Supports in-system programmability for flexible device updates. Contains 32 macro cells and 32 general-purpose I/O pins. Uses EEPROM memory technology for reliable logic storage. Maximum propagation delay time is 10 nanoseconds for fast performance.

Packaged in a 44-pin PLCC surface mount package. Operates over a voltage range of 4.75V to 5.25V. Suitable for industrial temperature range from -40°C to 85°C. Maximum operating frequency of 125 MHz for high-speed applications.

Provides individual output enable control for precise signal management. Manufactured in the Philippines with new product condition.

This CPLD from Microchip is a valuable component for industrial and commercial applications where programmable logic and in-system programmability features are critical. Explore more semiconductor solutions in EnvMart’s Programmable Logic ICs category for your electronic design needs.
