XP Power DC/DC Converter Through Hole Mount, 12.7mm x 12.7mm, 0-12V Input, 200V Output, 2.5 mA Output Current, 0.5W Q02-12
Specifications
| Country of Origin | Vietnam |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power Q DC/DC Converter, 200V dc/ 2 |
| Brand | XP Power |
| Length | 12.7mm |
| Model | Q02-12 |
| Gross Weight | 4.3g |
| Width | 12.7mm |
| Mount Type | Through Hole |
| Series | Q |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -25°C |
| MTBF | 3000000h |
| Number of outputs | 1 |
| Ripple and Noise | 0.25% Pk-Pk |
| Maximum Output Power | 0.5W |
| Maximum Input Voltage | 12V dc |
| Minimum Input Voltage | 0V dc |
| Number of Pins | 6 |
| Output Voltage 1 | 200V dc |
| Output Current 1 | 2.5mA |
| Isolation Voltage | 500V dc |
Key Features
- Ultra miniature and highly reliable converter designed for small size and low weight applications.
- Operates with 0 to 12 V DC input voltage and outputs 200 V DC at 2.5 mA current.
- Mount type is through hole with a 6-pin configuration for easy PCB mounting.
- Features low ripple and EMI/RFI noise of 0.25% peak-to-peak ensuring stable output performance.
- Operating temperature range from -25 °C to 70 °C for robust performance in varied environments.
- Isolation voltage up to 500 V DC for safety and enhanced circuit isolation.
- Short circuit protection with low leakage current suitable for sensitive applications.
- Applications include avalanche photodiodes, photomultiplier tubes, piezo devices, sustaining ion pumps, and capacitor charging.
Product Description
XP Power Q02-12 is an ultra miniature DC/DC converter designed for high voltage isolated DC conversion with a small footprint measuring 12.7 mm by 12.7 mm. It operates with a DC input voltage range from 0 V to 12 V and provides a stable output voltage of 200 V DC with a current of 2.5 mA and maximum output power of 0.5 W. This through-hole mount converter features a 6-pin configuration that facilitates easy integration into printed circuit boards.
The device offers excellent low ripple and noise characteristics at 0.25% peak-to-peak, contributing to precise and stable output critical for sensitive applications. It includes short circuit protection and maintains a low leakage current, ensuring safe operation within electrical systems. The isolation voltage rating of 500 V DC provides enhanced safety and circuit separation.
Designed to operate reliably across a broad temperature range from -25 °C to 70 °C, the Q02-12 is ideal for use in environments with varying thermal conditions. Its extremely low weight of 4.3 grams and compact size make it suitable for applications where space and weight are key constraints.
This DC/DC converter finds applications in advanced electronic systems such as avalanche photodiodes, photomultiplier tubes, light sources, piezoelectric devices, sustaining ion pumps, electrophoresis equipment, printers, igniters, and capacitor charging circuits.
Ultra miniature, reliable DC to high voltage DC conversion. Small size and lightweight design for compact applications. Low ripple and noise output ensures signal integrity. Wide operating temperature range with robust performance.
Short circuit protection and low leakage current. High isolation voltage for safety and circuit integrity. Through hole mount type for standard PCB assemblies. Applications include photodiodes, ion pumps, piezo devices, and more.
Manufactured in Vietnam under stringent quality standards.
This product is ideal for industrial, laboratory, and commercial electronics requiring reliable high voltage DC conversion in a miniature form factor. Explore more DC/DC Converters by XP Power and other brands at EnvMart to find ideal solutions for your power conversion needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates with a DC input voltage range from 0 V to 12 V.
This model provides a stable output voltage of 200 V DC with a current of 2.5 mA.
The maximum output power is 0.5 W.
It has a compact footprint measuring 12.7 mm by 12.7 mm.
It features a through hole mount type with a 6-pin configuration for easy PCB integration.
The operating temperature range is from -25 °C to 70 °C.
It has an isolation voltage rating of 500 V DC, providing enhanced safety and circuit separation.
It offers low ripple and noise characteristics at 0.25% peak-to-peak, ensuring stable output performance.
It includes short circuit protection and maintains low leakage current, making it suitable for sensitive applications.
This converter is suitable for applications such as avalanche photodiodes, photomultiplier tubes, piezo devices, and capacitor charging.
The gross weight is 4.3 grams, making it lightweight for compact applications.
It is manufactured in Vietnam under stringent quality standards.
