Roxburgh EMC Flange RFI Filter 10 A 500V AC 60Hz, Stud Termination, 3 Phase KMF310

Free Delivery in India | Lowest Global Shipping Charges

Roxburgh EMC Flange RFI Filter 10 A 500V AC 60Hz, Stud Termination, 3 Phase KMF310

Name: Roxburgh EMC Flange RFI Filter 10 A 500V AC 60Hz, Stud Termination, 3 Phase KMF310
Brand: Roxburgh EMC
SKU: 141398
Price: 167.32 USD
Availability: InStock



Category Power Line Filters Brand Roxburgh EMC Condition New

Specifications

Country of Origin	United Kingdom
Brand	Roxburgh EMC
Height	79mm
Length	179mm
Model	KMF310
Depth	45mm
Mount Type	Flange
Operating Frequency	60Hz
Series	KMF
Maximum Operating Temperature	100°C
Number Of Stages	1
Resistance	14mΩ
Capacitance	1μF
Minimum Operating Temperature	-25°C
Maximum Current	10A
Number of Phases	3
Leakage Current	3.4mA
Maximum Voltage	500V ac
Inductance	2.8mH
Standards/Approvals	UL1283
Termination Style	Stud
Power Loss	1.4W

Key Features

Designed to reduce electromagnetic interference in power line circuits.
Features flange mounting with stud termination for robust installation.
Operates efficiently over a temperature range of -25°C to 100°C.
Compact dimensions of 179mm length, 79mm height, and 45mm depth ensure space-saving installation.
Built to meet UL1283 safety standards for power line filters.
Incorporates a capacitance of 1μF and inductance of 2.8mH for effective filtering.
Leakage current rating is 3.4mA with a low resistance of 14mΩ.
Power loss is minimal at 1.4W, ensuring energy efficiency.

Product Description

Roxburgh EMC KMF310 Flange RFI Filter is engineered as a robust 3 phase filter to mitigate EMI in industrial power line applications. Rated for 10 A maximum current and 500V AC operating voltage at 60Hz frequency, it is suitable for use in machine tools, industrial controls, and mechanical equipment.

This filter features a flange mount design with stud termination, enabling secure and reliable installation in control cabinets and panels. Its compact size, measuring 179mm in length, 79mm in height, and 45mm in depth, supports space-limited industrial environments.

Constructed to operate from -25°C up to 100°C, it maintains performance across variable and demanding conditions, with a capacitance of 1μF and inductance of 2.8mH providing effective suppression of high-frequency noise.

The filter’s leakage current is rated at 3.4mA, with a low internal resistance of 14mΩ to minimize voltage drops. Power loss is limited to 1.4W, contributing to operational efficiency and reduced heat generation.

Compliant with the UL1283 standard, the KMF310 assures safety and quality. Manufactured in the United Kingdom, it aligns with stringent industrial requirements for EMI filtering solutions.

Designed to reduce electromagnetic interference in power line circuits. Features flange mounting with stud termination for robust installation. Operates efficiently over a temperature range of -25°C to 100°C. Compact dimensions optimize space usage in control panels.

UL1283 certified for industrial safety compliance. Capacitance of 1μF and inductance of 2.8mH offers superior noise suppression. Low leakage current and resistance improve electrical performance. Minimal power loss enhances energy efficiency.

Suitable for industrial and machine tool equipment applications.
