XP Power Isolated DC/DC Converter 12V DC 250mA 6W 36V DC Input Through Hole JCD0624D12
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power JCD DC/DC Converter, 12V dc/ 250 mA, 36V |
| Brand | XP Power |
| Efficiency | 83% |
| Length | 31.75mm |
| Model | JCD0624D12 |
| Depth | 10.4mm |
| Width | 20.32mm |
| Mount Type | Through Hole |
| Series | JCD |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 1100000h |
| Number of outputs | 2 |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 36V dc |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 18V |
| Number of Pins | 24 |
| Output Voltage 1 | 12V dc |
| Output Current 1 | 250mA |
| Output Voltage Adjustment Range | ±11.88 V dc, ±12.12 V dc |
| Isolation Voltage | 1.6kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Supports input voltages from 18V DC up to 36V DC for flexible use.
- Provides two outputs with an output voltage adjustment range of ±11.88 V DC to ±12.12 V DC.
- Features high isolation voltage of 1.6kV DC ensuring safety in electrical environments.
- Compact DIP package measuring 31.75mm length by 20.32mm width and 10.4mm depth for easy PCB integration.
- Wide operating temperature range from -40°C to 100°C suitable for harsh industrial conditions.
- Continuous short circuit protection enhances reliability and protects circuitry.
- High efficiency of 83% improves power utilization and reduces heat generation.
- Designed with 24 pins and through-hole mount type for secure and stable placement.
Product Description
XP Power's JCD0624D12 is a reliable isolated DC/DC converter delivering 12V DC output at 250 mA with a maximum power of 6W, operating with input voltages ranging from 18V DC to 36V DC. Its through-hole DIP package with dimensions of 31.75mm by 20.32mm and depth of 10.4mm allows easy integration onto PCB boards. This converter is engineered to offer continuous short circuit protection and operates efficiently at 83%, making it suitable for demanding industrial applications.
Its isolation voltage rating of 1.6 kV DC provides excellent electrical isolation, ensuring safety and performance in power supply designs, while the wide operating temperature range from -40°C to 100°C enables the unit to withstand harsh environmental conditions. The JCD series is known for its high MTBF of 1,100,000 hours, indicating exceptional longevity and reliability in continuous operation.
This converter is suitable for use in industrial, laboratory, and electronic equipment power supplies requiring isolated DC/DC voltage conversion with steady output current. It complies with RoHS environmental regulations, making it a sound choice for modern electronics manufacturing.
Supports input voltages from 18V DC up to 36V DC for flexible use. Provides two outputs with an output voltage adjustment range of ±11.88 V DC to ±12.12 V DC. Features high isolation voltage of 1.6kV DC ensuring safety in electrical environments.
Compact DIP package measuring 31.75mm length by 20.32mm width and 10.4mm depth for easy PCB integration. Wide operating temperature range from -40°C to 100°C suitable for harsh industrial conditions. Continuous short circuit protection enhances reliability and protects circuitry.
High efficiency of 83% improves power utilization and reduces heat generation. Designed with 24 pins and through-hole mount type for secure and stable placement. MTBF of 1,100,000 hours highlights long operational durability.
RoHS compliant ensuring environmental and safety standards. Explore the comprehensive range of DC/DC Converters and power supplies at EnvMart to find the ideal components for your industrial and electronic projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is from 18V DC to 36V DC.
This unit has a maximum output power of 6W.
The dimensions of the converter are 31.75mm in length, 20.32mm in width, and 10.4mm in depth.
It operates with an efficiency rating of 83%.
This converter features a high isolation voltage of 1.6kV DC.
The operating temperature range is from -40°C to 100°C.
This model provides two outputs.
The output voltage adjustment range is ±11.88 V DC to ±12.12 V DC.
It is designed for through-hole mounting.
The mean time between failures (MTBF) for this model is 1,100,000 hours.
Yes, it complies with RoHS environmental regulations.
This converter comes in a DIP (Dual In-line Package) type.
