Wurth Elektronik 381 Series 5-Contact Pluggable Terminal Block, 2.5 mm Pitch, 1 Row, 300V, 12A 691381000005

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 381 Series 5-Contact Pluggable Terminal Block, 2.5 mm Pitch, 1 Row, 300V, 12A 691381000005

Name: Wurth Elektronik 381 Series 5-Contact Pluggable Terminal Block, 2.5 mm Pitch, 1 Row, 300V, 12A 691381000005
Brand: Wurth Elektronik
SKU: 140401



Category Pluggable Terminal Blocks Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	300V
Brand	Wurth Elektronik
Colour	Green
Orientation	Vertical
Current	12A
Length	13.1mm
Depth	18.9mm
Width	11.8mm
Housing Material	Polyamide
Series	381
Number of Rows	1
Pitch	2.5mm
Number of Contacts	5
Connector Gender	Male
Minimum Wire Size mm²	0.21mm²
Maximum Wire Size mm²	1.31mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	16AWG
Wire Connection Method	Cable Entry Screwless

Key Features

This terminal block features a 2.5 mm pitch and a single row configuration.
It supports 5 electrical contacts with screwless push-in spring wire termination.
The housing is constructed from durable polyamide with a green color finish.
Suitable for wire sizes from 24 AWG up to 16 AWG (0.21 to 1.31 mm²).
Designed for vertical orientation with a compact length of 13.1 mm and width of 11.8 mm.
Its maximum current rating is 12 amperes and voltage rating is 300 volts.
The connector is male gender and does not carry specific certifications.
Ideal for electronics, industrial automation, and electrical control systems.

Product Description

Wurth Elektronik 691381000005 Pluggable Terminal Block belongs to the 381 Series and offers a reliable and compact connection solution for electronic components and industrial automation applications. This 5-contact terminal block features a 2.5 mm pitch and a single row configuration that supports secure cable wiring with a screwless push-in spring mechanism, ensuring rapid and stable wire connection without screws.

The housing is made from robust polyamide material, providing excellent insulating properties and durability with a green-colored finish. The vertical orientation and the compact dimensions of 13.1 mm length, 11.8 mm width, and 18.9 mm depth make it suitable for dense PCB layouts and modular connector designs.

It supports a current rating of 12 amperes and voltage up to 300 volts, accommodating wire sizes from 24 AWG (0.21 mm²) up to 16 AWG (1.31 mm²). This male connector is designed for long-term reliable contact in power and signal transmission circuits typical in industrial electronics, automation control panels, test equipment, and electrical installation systems.

The 381 Series terminal block connectors do not currently carry formal approvals or standards but are engineered for dependable performance in commercial and industrial environments.

Wurth Elektronik provides matching terminal block headers (WR-TBL 382 series) to enable two-part pluggable connections for easy maintenance and replacement in system assemblies. This product features 5 contacts in a single row with 2.5 mm pitch for compact wiring.

Screwless push-in spring wire connection allows fast and secure cable entry without tools. Robust polyamide housing provides strong insulation and mechanical protection. Supports cable cross sections from 0.21 to 1.31 mm², covering AWG 24 to 16 sizes.

Rated for 12A current and 300V voltage, ideal for signal and power circuits. Compact vertical connector design suits dense PCB and automation applications. Complements the 382 series terminal block headers for two-part pluggable connection systems.

Manufactured in China adhering to rigorous quality and material standards. Explore more Pluggable Terminal Blocks by Wurth Elektronik within the Electronics Components category at EnvMart.
