WEG CWC Contactor 230V AC Coil 4-Pole 12 A 5.5 kW Motor Control 2 NO/2 NC 690V AC CWC012-00-22D24

Free Delivery in India | Lowest Global Shipping Charges

WEG CWC Contactor 230V AC Coil 4-Pole 12 A 5.5 kW Motor Control 2 NO/2 NC 690V AC CWC012-00-22D24



Category Contactors Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Function	Motor Control
Length	58mm
Model	CWC012-00-22D24
Depth	52mm
Width	45mm
Mount Type	DIN Rail
Series	CWC
Power Rating	5.5kW
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Number of Poles	4
Standards/Approvals	IEC, RoHS, UL
Contact Voltage	690V ac
Coil Voltage	230V ac
Normal State Configuration	2 NO/2 NC
Contact Current	12A
Auxiliary Contact Configuration	2 NO/2 NC
Operational Current Ie	12A
Control Circuit Voltage Uc	230V ac
Contactor Application	Motor Control
Pole and Throw Configuration	4PST

Key Features

Operates with a coil voltage of 230V AC for standard industrial applications.
Equipped with 4 poles supporting a contact current of 12 amperes.
Rated power handling of 5.5 kW at 230V AC, suitable for controlling electric motors.
Features 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts for flexible control circuits.
Mounts easily on DIN rails with screw terminals for secure wiring.
Designed for operation between -25°C to 55°C temperature range.
Compact dimensions (45mm width, 52mm depth, 58mm length) for space-saving installations.
Conforms to IEC, RoHS, and UL standards ensuring safety and compliance.

Product Description

WEG CWC012-00-22D24 contactor is a robust and compact device designed for motor control applications. It features a coil voltage of 230V AC and a 4-pole configuration capable of handling 12 amperes of contact current. Rated at 5.5 kW power, it supports switching operations in industrial electrical control systems.

This contactor includes 2 normally open and 2 normally closed auxiliary contacts, allowing versatile connectivity options in control circuits. The unit mounts directly onto DIN rails and uses screw terminals to ensure reliable wiring and easy installation.

Constructed to operate within a temperature range of -25°C to 55°C, this WEG contactor meets IEC, RoHS, and UL standards providing assurance of safety and quality. Its compact dimensions (45mm W x 52mm D x 58mm L) make it suitable for installations where space is limited.

The CWC series by WEG is engineered for professional electric motor switching applications, offering modularity and high reliability. This contactor is ideal for industrial automation, manufacturing, HVAC, and other electrical control systems requiring precise motor management.

Operates with a coil voltage of 230V AC for standard industrial applications. Equipped with 4 poles supporting a contact current of 12 amperes. Rated power handling of 5.5 kW at 230V AC, suitable for controlling electric motors.

Features 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts for flexible control circuits. Mounts easily on DIN rails with screw terminals for secure wiring. Designed for operation between -25°C to 55°C temperature range.

Compact dimensions (45mm width, 52mm depth, 58mm length) for space-saving installations. Conforms to IEC, RoHS, and UL standards ensuring safety and compliance. Application focused on motor control in industrial automation and electrical systems.

Manufactured in Brazil, part of WEG’s CWC series for robust and reliable performance. Explore the comprehensive range of Contactors and electrical automation solutions at EnvMart to find suitable equipment for your industrial needs.
