Intersil Line Transceiver Differential Non-Inverting 5V 8-Pin SOIC ISL3158EIBZ-T7A
Specifications
| Country of Origin | India |
|---|---|
| Brand | Intersil |
| Model | ISL3158EIBZ-T7A |
| Mount Type | Surface |
| Output type | Differential |
| Series | ISL3158E |
| Input Type | Differential |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Polarity | Non-Inverting |
| IC Type | Line Transceiver IC |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Logic Function | Bus Transceiver |
| Minimum Supply Voltage | 5V |
Key Features
- Operates at a minimum supply voltage of 5V and maximum supply voltage of 5.5V.
- Designed for reliable data transmission over long twisted pair wiring using RS-485 standard.
- Supports both half duplex and full duplex communication modes.
- Surface mount device suited for compact electronics designs.
- Operational temperature range from -40°C to 85°C, suitable for industrial environments.
- Bus transceiver logic function facilitating robust line interface applications.
- Complies with the ISL3158E series specifications from Intersil.
- Non-automotive standard device for general semiconductor applications.
Product Description
Intersil ISL3158EIBZ-T7A is a high-performance line transceiver IC designed for use in differential signal transmission systems, featuring non-inverting polarity and housed in an 8-pin SOIC surface mount package. It operates with a supply voltage range of 5V to 5.5V and supports RS-485 communication protocols, enabling reliable half duplex and full duplex data transmission over long twisted pair wiring.
The device functions as a bus transceiver, providing differential input and output signals which enhance noise immunity and signal integrity in industrial and communication equipment applications. Its robust operating temperature range from -40°C to 85°C makes it ideal for use in harsh environments encountered in industrial, manufacturing, and instrumentation fields.
This line interface IC is suited for electronics designs requiring compact, surface-mounted devices with precise and reliable data communication capabilities. While not compliant with automotive standards, it meets Intersil's ISL3158E series quality and performance standards.
Operates within a supply voltage range of 5V to 5.5V. Supports differential input and output signaling to reduce noise impact. Provides non-inverting signal transmission ensuring data integrity. 8-pin SOIC surface mount package for seamless PCB integration.
Wide temperature range of -40°C to 85°C for durability in industrial settings. Designed for RS-485 line driver and receiver applications. Facilitates half duplex and full duplex communication modes. Robust bus transceiver logic suitable for line interface semiconductor roles.
This line transceiver is commonly utilized in industrial automation, instrumentation, data acquisition systems, and communication interfaces requiring robust differential signaling over long cable runs. EnvMart offers this product as part of its semiconductor line interface IC category, catering to advanced electronic component needs in multiple industrial sectors.
