i-Autoc KSID Series Solid State Relay Panel Mount 25A Load 530V AC Load 4-15V DC Control KSID480LD25

The i-Autoc KSID480LD25 is a reliable KSID Series Solid State Relay designed for panel mount applications requiring 25A load current capacity and a maximum 530V AC load voltage. It operates with a control voltage range of 4V dc to 15V dc, providing versatile control options for various industrial environments.

This solid state relay supports zero cross switching, enabling reduced electrical noise and improved load switching performance. Its construction includes quick connect terminals to facilitate easy and secure wiring. The relay outputs using an SCR for efficient AC load control.

With dimensions of 21.5mm in height and 58.4mm in length, this relay offers a compact solution that fits standard panels. It maintains low off-state leakage current of 2mA, minimizing energy losses during inactive periods. The relay is rated for operation in temperatures ranging from -30°C to 80°C, ensuring suitability for demanding industrial conditions.

Protection and standards compliance include a RoHS certification and IP20 safety cover, safeguarding both operator and equipment. The unit is made in China and is designed to handle resistive, inductive, or capacitive loads efficiently.

Applicable across automation, industrial control, manufacturing, and electrical panel construction, the i-Autoc KSID480LD25 reliably delivers consistent performance for AC load switching.

Panel mount design enables secure and easy installation. Supports a maximum load current of 25 amperes. Operates with a DC control voltage range from 4V to 15V. Features zero cross switching to reduce electrical noise. Quick connect terminal type for fast wiring.

Compact dimensions with 21.5mm height and 58.4mm length. Low off-state leakage current of 2mA ensures safety and efficiency. SCR output type suitable for AC loads up to 530V. Operating temperature range from -30°C to 80°C for robust performance.

Certified RoHS compliant and equipped with IP20 safety cover protection. Explore more Solid State Relays and industrial automation products on EnvMart to enhance your control systems with trusted performance.
