i-Autoc KSI Series Solid State Relay 60A Load Panel Mount 530V AC Load 32V Control KSI480D60-L(068)

i-Autoc KSI480D60-L(068) Solid State Relay is an industrial-grade single phase relay designed for panel mount applications. It can handle a maximum load current of 60A and a load voltage up to 530V AC, controlled with a voltage range of 4V to 32V. This relay incorporates advanced SCR and Triac output types and zero cross switching function, optimizing performance and reducing electrical noise.

Constructed with an IP20 touch-safe cover, the device ensures protection against accidental contact with live components. The relay is suitable for resistive, inductive, and capacitive loads commonly found in HVAC systems, plastics machinery, incubation chambers, elevators, lighting controls, and fountain controllers.

Operating temperature ranges from -30°C to 80°C, allowing use in challenging industrial environments. Screw terminal connections facilitate firm and reliable wiring installation. The minimal off-state leakage current of 3mA enhances energy efficiency and safety.

The compact form factor, measuring 27mm in height, 45.7mm in width, and 58.6mm in length, integrates easily into control panels. Compliance with CCC, RoHS, and CE standards confirms the relay's adherence to international safety and environmental protocols.

The relay features zero cross switching for efficient and safe operation. It has a screw terminal type ensuring secure electrical connections. The solid state relay supports loads with voltage ranging from 48V AC minimum to 530V AC maximum.

Operating temperature range is from -30°C up to 80°C ensuring durability in diverse environments. Equipped with IP20 touch-safe cover providing protection to live parts. Output type includes SCR and Triac for versatile control options.

Leakage current in off state is minimal at 3mA. The relay complies with CCC, RoHS, and CE standards for quality assurance. Compact dimensions with height of 27mm, width 45.7mm, and length 58.6mm.

This i-Autoc KSI Series Solid State Relay is ideal for industrial, manufacturing, HVAC, and automation control panel applications, delivering reliable switching capabilities. Explore other high-quality Solid State Relays and electrical components at EnvMart's Industrial Automation category.
