i-Autoc KSMD48D4-12 Solid State Relay, 4 A Load Current, 58 V DC Load Voltage, PCB Mount, 15 V DC Control Voltage
Specifications
| Country of Origin | China |
|---|---|
| Brand | i-Autoc |
| Height | 15mm |
| Length | 28.2mm |
| Model | KSMD48D4-12 |
| Width | 16.38mm |
| Mount Type | PCB |
| Output type | MOSFET |
| Series | KSMD*D/KSM |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -30°C |
| Terminal type | PCB Terminal |
| Switching Function | DC Switching |
| Maximum Load Current | 4A |
| Standards/Approvals | RoHS |
| Maximum Load Voltage | 58V dc |
| Minimum Load Voltage | 0V dc |
| Minimum Control Voltage | 1V dc |
| Maximum Control Voltage | 15V dc |
| Off State Leakage Current | 100μA |
| On State Resistance | 37mΩ |
Key Features
- Operates with a maximum control voltage of 15 V DC.
- Features MOSFET output type for efficient DC switching.
- Compact dimensions of 28.2mm length, 16.38mm width, and 15mm height.
- Designed to operate within temperature range of -30°C to 80°C.
- PCB terminal mounting for high density and reliable installation.
- Low on state resistance of 37mΩ ensures minimal power loss.
- Dielectric strength rated at 2500 Vrms for insulation safety.
- Compliant with RoHS standards for environmental safety.
Product Description
i-Autoc KSMD48D4-12 solid state relay offers a reliable solution for DC switching applications requiring up to 4 A load current at 58 V DC load voltage. Its compact PCB mount design facilitates integration into high density circuit boards and PLC control systems.
This SSR features MOSFET output type, offering efficient switching performance with low on-state resistance of 37mΩ to minimize power dissipation. It supports a control voltage up to 15 V DC and a minimum of 1 V DC, ensuring compatibility with a range of control circuits.
The relay can safely operate in ambient temperatures ranging from -30°C to 80°C, supporting industrial and automation environments. Its robust dielectric strength of 2500 Vrms enhances operational safety by providing effective isolation between input and output.
Engineered with PCB terminal mounting, the KSMD48D4-12 model simplifies installation in compact electronics assemblies. The relay is RoHS compliant, confirming adherence to environmental directives for hazardous substances.
Additional features include an off-state leakage current of merely 100μA, improving energy efficiency during inactivity. The solid state relay's dimensions of 28.2mm length, 16.38mm width, and 15mm height make it suitable for space-constrained applications.
Operates with a maximum control voltage of 15 V DC. Features MOSFET output type for efficient DC switching. Compact dimensions of 28.2mm length, 16.38mm width, and 15mm height. Designed to operate within temperature range of -30°C to 80°C.
PCB terminal mounting for high density and reliable installation. Low on state resistance of 37mΩ ensures minimal power loss. Dielectric strength rated at 2500 Vrms for insulation safety. Compliant with RoHS standards for environmental safety.
Off-state leakage current as low as 100μA.
This product is manufactured in China and suitable for industrial, electrical automation, and control applications requiring dependable Solid State Relays. Explore more relays and contactors suitable for advanced automation at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this solid state relay is 4 A.
It operates with a control voltage ranging from 1 V DC to a maximum of 15 V DC.
This solid state relay is rated for a maximum load voltage of 58 V DC.
It features a MOSFET output type, which is designed for efficient DC switching.
The dimensions of the KSMD48D4-12 are 28.2 mm in length, 16.38 mm in width, and 15 mm in height.
It is designed to operate within a temperature range of -30°C to 80°C.
The on-state resistance is 37 mΩ, which helps to minimize power loss during operation.
The off-state leakage current is as low as 100 μA, enhancing energy efficiency during inactivity.
This solid state relay is designed for PCB terminal mounting, allowing for high-density installations.
Yes, it is compliant with RoHS standards, confirming adherence to environmental directives for hazardous substances.
The dielectric strength is rated at 2500 Vrms, providing effective insulation safety between input and output.
It is suitable for industrial, electrical automation, and control applications requiring dependable solid state relays.
