i-Autoc KSI Series Solid State Relay 100A Load Panel Mount 280V AC Load 280V AC Control KSI240A100-L
Specifications
| Country of Origin | China |
|---|---|
| Brand | i-Autoc |
| Height | 27mm |
| Length | 58.6mm |
| Model | KSI240A100-L |
| IP Rating | IP20 |
| Width | 45.7mm |
| Mount Type | Panel |
| Output type | SCR, Triac |
| Series | KSI |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 100A |
| Standards/Approvals | CE, CCC, RoHS |
| Maximum Load Voltage | 280V ac |
| Minimum Load Voltage | 48V ac |
| Minimum Control Voltage | 90V ac |
| Off State Leakage Current | 5mA |
Key Features
- The relay supports a maximum load voltage of 280V AC and control voltage up to 280V AC.
- It features zero cross switching function for safe and reliable operation.
- Equipped with an IP20 rated touch-safe cover for user safety.
- Suitable for resistive, inductive, and capacitive loads.
- Operating temperature range from -30°C to +80°C for versatile industrial environments.
- Terminal type is screw, ensuring secure electrical connections.
- The relay output consists of SCR and Triac types for robust control.
- Designed for applications such as HVAC systems, plastics machinery, incubation chambers, elevators, and lighting control.
Product Description
i-Autoc KSI240A100-L Solid State Relay is an industrial-grade single-phase relay designed for high-current applications up to 100A with a panel mount feature. This relay supports a maximum load voltage of 280V AC and a wide control voltage range up to 280V AC, making it suitable for various industrial and commercial uses.
The relay incorporates zero cross switching technology, which significantly reduces electrical noise and surge currents, enhancing the longevity and performance of connected equipment. The IP20 rated touch-safe cover provides protection against accidental contact, ensuring operator safety during installation and maintenance.
Compatible with resistive, inductive, and capacitive loads, the KSI240A100-L relay offers versatile performance for demanding control tasks. The relay features screw terminals for secure electrical connections and an output type utilizing SCR and Triac devices for efficient switching.
Operating reliably in temperatures ranging from -30°C to +80°C, this solid state relay is ideal for harsh industrial environments such as HVAC control, plastics manufacturing, incubation machines, oiling machines, elevators, lighting systems, and fountain controllers.
With compact dimensions of 58.6mm length, 45.7mm width, and 27mm height, the relay is easy to integrate into control panels. It fulfills international standards including CE, CCC, and RoHS certifications, assuring compliance with safety and environmental regulations.
The relay supports a maximum load current of 100A. Feature zero cross switching for reduced electrical noise. Robust SCR and Triac output types for effective control. IP20 rated touch-safe cover for enhanced safety. Wide operating temperature range from -30°C to 80°C.
Screw terminal type for secure wiring connections. Suitable for resistive, inductive, and capacitive loads. Compact panel mount design with dimensions 58.6 × 45.7 × 27 mm. Compliant with CE, CCC, and RoHS standards.
This Solid State Relay is an essential component for industrial automation, electrical control, HVAC systems, and manufacturing processes that require reliable, durable, and safe load switching capabilities. Explore more industrial relays and electrical components in the Electronics & Electricals category at EnvMart for optimized industrial performance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this model is 100A.
It operates reliably within a temperature range of -30°C to +80°C.
This relay is suitable for resistive, inductive, and capacitive loads.
The maximum load voltage supported by this relay is 280V AC.
It features screw terminals for secure electrical connections.
The dimensions of this relay are 58.6mm in length, 45.7mm in width, and 27mm in height.
It incorporates zero cross switching technology, which reduces electrical noise and surge currents.
This model complies with CE, CCC, and RoHS standards.
The minimum control voltage for the KSI240A100-L is 90V AC.
The output type consists of SCR and Triac devices for efficient control.
It is suitable for applications such as HVAC systems, plastics machinery, incubation chambers, elevators, and lighting control.
It is equipped with an IP20 rated touch-safe cover to enhance user safety during operation.
