Sonel MIC-5001 5KV High Voltage Digital Insulation Tester
Specifications
| Power | 5 KV |
|---|---|
| Packaging Type | Box |
| Applications | Industrial |
| Voltage (V) | 240 V |
| Model | MIC-5001 |
Key Features
- measurement voltage selected within the range of 50...500 V with steps of 50 V and from 500 to 5000 V with steps of 100 V
- continuous reading of measured insulation resistance or leakage current
- automatic discharge of the measured objects capacitance upon completion of insulation resistance measurement
Product Description
Sonel MIC-5001 5KV High Voltage Digital Insulation Tester, Sonel MIC-5001 5KV High Voltage Digital Insulation Tester, The Sonel MIC-5001 functional insulation resistance meter is a reliable tool for measuring insulation resistance up to 5 too. Due to its excellent performance, it is used in a wide range of applications, including industry, railway industry, and housebuilding industry. The device combines a number of advantages - it is handy, has an ergonomic shape, and has a robust casing with a high level of protection. In addition, it is characterized by low battery power consumption, and it is possible to recharge the batteries even during measurements
- timing of measurement time T1, T2 and T3 for measurement of dielectric absorption ratio (DAR) and polarization index (PI)
- insulation resistance measurement according to the RampTest method and breakdown voltage measurement with ramping rate up to ~1 kV/s
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum measurement voltage of this model is 5 KV.
It measures insulation resistance with a voltage range selected from 50 V to 500 V in steps of 50 V, and from 500 V to 5000 V in steps of 100 V.
This insulation tester is suitable for industrial applications, including use in the railway and housebuilding industries.
The operating voltage for this unit is 240 V.
Yes, it features automatic discharge of the measured object's capacitance upon completion of the insulation resistance measurement.
It utilizes the RampTest method for insulation resistance measurement and also supports breakdown voltage measurement with a ramping rate of up to approximately 1 kV/s.
Yes, it has a timing feature for measurement time T1, T2, and T3 to calculate the dielectric absorption ratio (DAR) and polarization index (PI).
It is packaged in a box.
This model is characterized by low battery power consumption and allows for recharging even during measurements.
It has an ergonomic shape and a robust casing with a high level of protection.
The measurement voltage steps allow for precise selection of the voltage level for insulation testing, enhancing accuracy during measurements.
It provides continuous reading of the measured insulation resistance or leakage current during testing.
