i-Autoc KSI Series Solid State Relay Panel Mount 10 A Load 280 V AC Load 32V DC Control KSI240D10-L(068)

The i-Autoc KSI240D10-L(068) is a durable solid state relay designed for panel mounting in industrial automation and control applications that require reliable switching of AC loads. The relay supports a maximum load current of 10 A at a load voltage up to 280 V AC, making it suitable for a wide range of resistive, inductive, or capacitive load types.

This model features zero cross switching to minimize electrical noise and prolong the life of connected equipment. It accepts a control input voltage ranging from 4 V DC to 32 V DC, allowing flexible integration with various control systems.

With its Triac and SCR output types, this solid state relay ensures effective switching performance for single phase AC loads. Its compact panel mount form factor with screw terminals enables secure and space-saving installations in control panels.

Operating reliably between -30°C and 80°C, it is suitable for harsh industrial environments. The relay is compliant with multiple certifications including CCCs, cULus, CE, and TUV, guaranteeing international quality and safety standards.

Additional features include a low off-state leakage current of 5 mA to ensure energy efficiency during off cycles and an LED indicator for easy operational monitoring. The device is built for long service life with dielectric strength above 4000 VAC rms.

Supports a maximum load current of 10 A for reliable power handling. Designed for panel mounting with a screw terminal type for secure installation. Operates with zero cross switching function to reduce electrical noise.

Wide operating temperature range from -30°C to 80°C for harsh environments. Input control voltage range of 4V to 32V DC to suit varied control systems. Triac and SCR output type suitable for resistive, inductive, or capacitive loads.

Compact dimensions with length 58.4 mm and height 33.5 mm for space-efficient installation. Certified with standards including CCCs, cULus, CE, and TUV ensuring quality and safety. Low off-state leakage current of 5 mA to minimize power loss during operation.

Equipped with LED indicator for easy status monitoring during operation.

This solid state relay is ideal for industrial automation, electrical control panels, HVAC systems, and manufacturing equipment requiring precise and reliable AC load switching. Browse our Electronics & Electricals category for additional Solid State Relays and automation components.
