Samtec SMM Series Straight Surface PCB Socket 12-Contact 2 Row 2 mm Pitch Solder SMM-106-02-S-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.9A |
| Model | SMM-106-02-S-D |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy |
| Series | SMM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Contact System | Tiger Eye |
| Row Pitch | 1.27mm |
Key Features
- Provides a low profile socket strip with straight orientation and surface mount terminals.
- Features a Board-to-Board connector system with Tiger Eye contact system.
- Operates within a voltage rating of 350 V and current rating of 3.9 A.
- Constructed with a liquid crystal polymer housing and beryllium copper alloy contacts plated in gold.
- Supports a wide temperature range from -55°C to 125°C.
- Ideal for industrial and electronic component applications requiring reliable PCB connections.
- Designed for high-speed data transmission up to 8 Gbps.
Product Description
The Samtec SMM-106-02-S-D is a Straight Surface PCB Socket in the SMM Series designed for board-to-board connections with 12 contacts arranged in 2 rows and a 2 mm pitch solder termination.
This socket provides a low profile and straight mount that suits surface mounting, ensuring optimized PCB layout and reliable mechanical connection.
Built with a durable liquid crystal polymer housing, the socket incorporates beryllium copper alloy contacts with a gold plating finish to ensure excellent conductivity and corrosion resistance.
The contact system is the Tiger Eye design, facilitating up to 8 Gbps performance for high-speed signal transmission in demanding industrial and electronic applications. Its electrical ratings include a voltage rating of 350 V and a current capacity of 3.9 A, supporting robust power handling requirements.
The operating temperature range spans from -55°C minimum to 125°C maximum, providing resilience for various industrial environments. This product suits applications in electronics manufacturing, industrial automation, data communication equipment, and other high-reliability PCB assembly needs.
Low profile straight orientation suitable for surface mount PCBs. Board-to-board connector system compatible with SMM series. Liquid crystal polymer housing for durability and thermal stability. Beryllium copper alloy contacts with gold plating for conductivity and corrosion protection.
Supports 350 V and 3.9 A electrical ratings with wide temperature tolerance. Tiger Eye contact system enabling high-speed data transmission up to 8 Gbps. Ideal for industrial, manufacturing, and electronics assembly use cases.
Explore further PCB connector and socket solutions to complement your electronics assembly needs with EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a voltage rating of 350 V and a current rating of 3.9 A.
It operates within a temperature range of -55°C to 125°C.
This socket features 12 contacts arranged in 2 rows.
The housing is made from liquid crystal polymer, and the contacts are beryllium copper alloy plated in gold.
It uses a solder termination type for mounting.
The pitch size of this socket is 2 mm.
It features the Tiger Eye contact system, which allows for high-speed data transmission.
This model has a straight orientation suitable for surface mounting.
It supports high-speed data transmission up to 8 Gbps.
It is designed as a board-to-board connector system.
The socket is manufactured in India.
It is ideal for industrial and electronic component applications requiring reliable PCB connections.
