STMicroelectronics 2-Element Bi-Directional TVS Diode 230W, 3-Pin SOT-23 ESDCAN24-2BLY
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.4mm |
| Length | 3.04mm |
| Model | ESDCAN24-2BLY |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | ESDCANxx-2BLY |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Number of Elements per Chip | 2 |
| Clamping Voltage VC | 40V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Series |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 27V |
| Maximum Reverse Stand-off Voltage Vwm | 24V |
| Peak Pulse Power Dissipation Pppm | 230W |
| Maximum Peak Pulse Current Ippm | 5.5A |
| Maximum Reverse Leakage Current | 100nA |
Key Features
- Offers 230 W peak pulse power dissipation for effective voltage transient suppression.
- Features bi-directional operation for dual-line electrostatic discharge protection.
- Compact 3-pin SOT-23 surface mount package suitable for space-constrained applications.
- Minimum breakdown voltage of 27 V and maximum working voltage of 24 V.
- Fast response time and low leakage current of 100 nA enhances circuit protection.
- Wide operating temperature range from -40°C to 150°C for automotive and industrial environments.
- Complies with AEC-Q101 automotive standard ensuring reliability and quality.
- Designed to protect sensitive electronics from electrostatic discharge and electrical overstress.
Product Description
STMicroelectronics ESDCAN24-2BLY is a high-reliability 2-element bi-directional Transient Voltage Suppressor (TVS) diode designed for electrostatic discharge (ESD) and electrical overstress (EOS) protection in electronic circuits. Packaged in a compact, surface-mount 3-pin SOT-23 package, this TVS diode provides robust transient voltage suppression of up to 230 W peak pulse power dissipation.
This bi-directional TVS diode features a minimum breakdown voltage of 27 V and a maximum reverse stand-off voltage of 24 V, making it ideal for protecting sensitive data lines such as those used in Controller Area Network (CAN) bus applications. The device’s low leakage current of 100 nA minimizes power loss, and the maximum peak pulse current rating of 5.5 A assures effective transient fault absorption.
Operating over a wide temperature range from -40°C to 150°C, the ESDCAN24-2BLY meets the stringent requirements of automotive and industrial applications. It is compliant with the AEC-Q101 automotive standard, ensuring ruggedness and reliability in harsh environments.
The diode’s form factor with dimensions of 3.04 mm length, 1.75 mm width, and 1.4 mm height allows for space-saving PCB layouts where compact solutions are necessary. Its fast response and bi-directional operation enable dual-line ESD protection, safeguarding equipment from damaging voltage spikes and surges.
Offers 230 W peak pulse power dissipation for robust transient voltage protection. Bi-directional configuration suitable for dual-line ESD and EOS protection. Compact SOT-23 package enables low-profile mounting in space-restricted systems.
Low leakage current and fast response improve overall circuit reliability and efficiency. Wide operating temperature range supports automotive and industrial conditions. AEC-Q101 qualification guarantees automotive-grade performance and quality.
Ideal for protecting CAN bus interfaces and sensitive electronic equipment. Dimensions support compact, high-density PCB assembly.
This TVS Diode is widely used in electronic components, power and connectors, and semiconductor protection circuits within industrial, automotive, and telecommunications environments. It is a reliable choice for enhancing the durability and safety of sensitive systems exposed to high voltage transients.
Explore a broad portfolio of semiconductor protection devices at EnvMart to find comprehensive solutions for your electronic circuit protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ESDCAN24-2BLY offers a peak pulse power dissipation of 230 W for effective voltage transient suppression.
It has a minimum breakdown voltage of 27 V, which is critical for its operation in protecting sensitive electronics.
The maximum reverse stand-off voltage is 24 V, making it suitable for various applications requiring ESD protection.
This model has a maximum peak pulse current rating of 5.5 A, ensuring effective transient fault absorption.
The dimensions of this diode are 3.04 mm in length, 1.75 mm in width, and 1.4 mm in height, suitable for compact PCB layouts.
It operates over a wide temperature range from -40°C to 150°C, making it suitable for automotive and industrial environments.
The ESDCAN24-2BLY is packaged in a compact 3-pin SOT-23 surface mount package, ideal for space-constrained applications.
Yes, it complies with the AEC-Q101 automotive standard, ensuring reliability and quality for automotive applications.
The maximum reverse leakage current is 100 nA, which helps minimize power loss in circuits.
This bi-directional TVS diode provides dual-line electrostatic discharge (ESD) and electrical overstress (EOS) protection.
The ESDCAN24-2BLY features 2 elements per chip, enhancing its protective capabilities in electronic circuits.
It is widely used in protecting sensitive electronics, particularly in applications involving Controller Area Network (CAN) bus interfaces.
