Nexperia 5.1 V 300 mW Zener Diode, Single 2-Pin Surface Mount SOD-523 BZX585-B5V1,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 5.1 V 300 mW Zener Diode, Single 2-Pin Surface Mount SOD-523 BZX585-B5V1,115

Name: Nexperia 5.1 V 300 mW Zener Diode, Single 2-Pin Surface Mount SOD-523 BZX585-B5V1,115
Brand: Nexperia
SKU: 131811
Price: 0.06 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	0.65mm
Length	1.65mm
Model	BZX585-B5V1,115
Mount Type	Surface
Series	BZX585
Maximum Operating Temperature	150°C
Package Type	SOD-523
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	300mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	2μA
Nominal Zener Voltage Vz	5.1V
Zener Type	Voltage Regulator
Maximum Zener Impedance	60Ω
Typical Voltage Temperature Coefficient	-0.5mV/K
Surface Mount case	SOD-523

Key Features

The diode has a nominal Zener voltage of 5.1 V with a tolerance of ±2%.
It features a surface mount SOD-523 package suitable for compact electronic designs.
The maximum power dissipation is 300 mW, supporting efficient voltage regulation.
Operating temperature ranges from -65°C to 150°C, ensuring reliability in various environments.
The device conforms to automotive standard AEC-Q101 for enhanced quality assurance.
The maximum reverse leakage current is 2 μA, ensuring minimal current losses.
The maximum Zener impedance is 60 Ω which supports stable voltage regulation under load.
Its compact dimensions are length 1.65 mm and height 0.65 mm, facilitating high-density PCB layouts.

Product Description

Nexperia BZX585-B5V1,115 Zener Diode is a high-quality semiconductor component ideal for voltage regulation applications requiring a nominal Zener voltage of 5.1 V and power dissipation capacity of 300 mW. The single-element diode comes in a compact 2-pin surface mount SOD-523 package that fits into dense PCB assemblies used in consumer electronics, automotive electronics, and industrial control systems.

Designed for durability, it operates reliably across a wide temperature range of -65°C to 150°C and conforms to automotive standard AEC-Q101. Its typical voltage temperature coefficient of -0.5 mV/K offers precise performance in temperature-variable environments. The maximum reverse leakage current of 2 μA ensures low power loss, making this ideal for voltage regulator circuits and voltage reference standards.

The diode's maximum power dissipation of 300 mW allows it to handle moderate currents while maintaining stable operation. Its maximum Zener impedance of 60 Ω supports consistent voltage regulation when subjected to varying load currents. Measuring only 1.65 mm in length and 0.65 mm in height, this device supports miniature and surface-mount applications in HVAC, automotive, and manufacturing electronics sectors.

This Nexperia BZX585-B5V1,115 Zener Diode is widely used in industrial semiconductor applications requiring high reliability and small form factor components. Its 2% voltage tolerance ensures predictable voltage clamping performance in power supply circuits, signal processing, and protection circuits.

The diode provides precise 5.1 V voltage regulation in a surface mount package. 300 mW power dissipation supports moderate power applications. Wide operating temperature range from -65°C to 150°C. Compact 2-pin SOD-523 package dimensions 1.65 mm by 0.65 mm.

Complies with automotive standard AEC-Q101 for enhanced quality. Low reverse leakage current and impedance for efficient regulation. Suitable for electronic component manufacturing and industrial control circuits. Explore more high-performance semiconductor components and Zener Diodes on EnvMart for industrial and manufacturing needs.
