Bourns 1-Element Bi-Directional TVS Diode Surface Mount 600W, 16.7V Breakdown Voltage, DO-214 SMBJ15CA
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | Bourns |
| Height | 2.42mm |
| Length | 4.57mm |
| Model | SMBJ15CA |
| Width | 3.94mm |
| Mount Type | Surface |
| Series | SMB |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 24.4V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 16.7V |
| Maximum Reverse Stand-off Voltage Vwm | 15V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 50A |
| Maximum Reverse Leakage Current | 5μA |
Key Features
- This diode has a minimum breakdown voltage of 16.7 V for reliable voltage clamping.
- The device features bi-directional configuration for protection against voltage spikes from both polarities.
- It offers a peak pulse power dissipation of 600 W and maximum peak pulse current of 50 A for robust transient suppression.
- The compact DO-214 package with length 4.57 mm and width 3.94 mm facilitates surface mounting on PCBs.
- Operating temperature range is wide, from -55°C up to 150°C, supporting harsh industrial environments.
- The clamping voltage is rated at 24.4 V to limit voltage spikes effectively.
- The diode includes ESD protection and has 2 pins for electrical connection.
- It complies with automotive standard AEC-Q101 for use in automotive applications.
Product Description
Bourns SMBJ15CA is a 1-element bi-directional Transient Voltage Suppressor (TVS) diode designed for surface mount applications requiring high peak pulse power of 600 W. Packaged in a DO-214 SMB style, it provides vital protection for electronic circuits against voltage transient damage.
This diode is configured as a single bi-directional element, making it suitable for protecting signals and power lines from transient overvoltages in both directions. It has a minimum breakdown voltage of 16.7 V and a maximum reverse stand-off voltage of 15 V, ensuring it activates only during voltage spikes above normal operating levels.
The SMBJ15CA diode is compact with a length of 4.57 mm, width of 3.94 mm, and height of 2.42 mm, offering easy integration into PCB layouts. It supports a maximum peak pulse current of 50 A and a clamping voltage of 24.4 V to efficiently clamp surges and protect sensitive electronic components.
This device is qualified to the automotive industry standard AEC-Q101, confirming reliability for automotive and industrial applications. It operates across a wide temperature range from -55°C to 150°C, making it suitable for harsh environments. The diode features very low maximum reverse leakage current of 5 µA, reducing quiescent power consumption.
Typical use cases for the SMBJ15CA include transient voltage protection in electronic equipment, communications systems, power supplies, and automotive electronics. Its 2-pin design and surface mount configuration facilitate automated assembly and reliable performance in transient surge suppression.
This diode has a minimum breakdown voltage of 16.7 V for reliable voltage clamping. It provides 600 W peak pulse power dissipation for transient protection. The device is bi-directional for protecting circuits from voltage spikes in both polarities.
Operates from -55°C to 150°C for broad environmental compatibility. Complies with automotive standard AEC-Q101 to ensure high reliability. Low maximum reverse leakage current of 5 µA minimizes power loss. Compact DO-214 SMB surface mount package for easy PCB integration.
Clamping voltage of 24.4 V limits voltage surges effectively. Suitable for transient voltage suppression in industrial, automotive, and electronic applications.
Discover a wide range of semiconductor protection devices and components in the Electronics & Electricals category at EnvMart to support your industrial and electronics design needs.
Explore more products in our TVS Diode category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SMBJ15CA diode has a peak pulse power dissipation of 600 W, providing robust transient suppression for electronic circuits.
This diode has a minimum breakdown voltage of 16.7 V, ensuring reliable voltage clamping during transient events.
The clamping voltage for this model is rated at 24.4 V, which helps limit voltage spikes effectively.
The SMBJ15CA supports a maximum peak pulse current of 50 A, allowing it to handle significant transient events.
This model has a length of 4.57 mm, a width of 3.94 mm, and a height of 2.42 mm, making it compact for surface mounting.
The diode operates across a wide temperature range from -55°C to 150°C, suitable for harsh industrial environments.
This diode features a 2-pin design, facilitating easy integration into PCB layouts.
It complies with the automotive standard AEC-Q101, ensuring reliability for automotive applications.
The maximum reverse leakage current for the SMBJ15CA is 5 µA, which helps minimize power loss during operation.
This model is configured as a single bi-directional element, providing protection against voltage spikes from both polarities.
The SMBJ15CA is packaged in a DO-214 SMB style, suitable for surface mount applications.
This diode is suitable for transient voltage protection in electronic equipment, communications systems, power supplies, and automotive electronics.
