Nichicon YX Series Film Capacitor Radial Mount 330nF Capacitance 50V AC 50V DC 7.5mm Lead Pitch 85°C Operating QYX1H334KTP

Nichicon QYX1H334KTP Film Capacitor belongs to the YX series, featuring a radial mount design for compact and efficient PCB integration. This capacitor offers 330nF capacitance rated at 50V AC and 50V DC voltages, making it suitable for various electronic applications requiring stable and reliable energy storage.

The capacitor construction uses high-quality polyester film paired with aluminium foil dielectric, encapsulated within a flame-retardant epoxy resin which also provides excellent resistance to humidity and solvent exposure. It maintains performance at a maximum operating temperature of 85°C, ensuring durability under demanding industrial conditions.

Physically, the capacitor measures 12.5mm in length, 16mm in height, and 8mm in depth with a lead pitch of 7.5mm and lead diameter of 0.6mm, compatible with standard PCB layouts. The pin count of 2 facilitates secure and straightforward electrical connections.

This component complies with RoHS directives, guaranteeing it meets stringent environmental and safety regulations. Manufactured in Japan, the product reflects superior quality and consistency, making it a trusted choice for engineers and designers in industrial, commercial, and laboratory electronics.

Typical use cases include power supply circuits, filtering applications, and general passive component needs in electronic assemblies. The radial mount Film Capacitor supports efficient circuit design by providing stable capacitance with low losses and long-term reliability.

Constructed with polyester film and aluminium foil dielectric materials. Designed with radial mount type for easy PCB installation. Features flame-retardant epoxy resin coating resisting humidity and solvents. Compact dimensions of 12.5mm length, 16mm height, and 8mm depth.

Suitable for commercial and industrial electronic applications requiring reliable capacitance. Compliant with RoHS standards ensuring environmental safety. Lead diameter is 0.6mm and pin count is 2 for secure connections.
