Nichicon Aluminium Electrolytic Capacitor 1mF 6.3V Radial Through Hole Polar Electrolytic RL80J102MDN1KX
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 6.3V |
| Diameter | 8mm |
| Brand | Nichicon |
| Height | 8mm |
| Length | 8mm |
| Model | RL80J102MDN1KX |
| Packaging | Box |
| Mount Type | Radial, Through Hole |
| Construction | Radial Can |
| Series | L8 |
| Termination Type | Radial Lead |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±20 % |
| Lifetime | 2000 h |
| Capacitance | 1mF |
| Minimum Operating Temperature | -55°C |
| Polarity | Polar |
| Dissipation Factor | 0.12% |
| Leakage Current | 1.3mA |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Lead Pitch | 3.5mm |
| Equivalent Series Resistance ESR | 9mΩ |
| Capacitor Ripple Current | 5.7A |
Key Features
- Features a 1 millifarad capacitance suitable for power filtering and decoupling.
- Operates at a rated voltage of 6.3 volts with polar construction.
- Constructed with a radial can and radial lead termination for through-hole PCB mounting.
- Supports high ripple current up to 5.7 amperes for enhanced durability.
- Capacitor ESR is ultra-low at 9 milliohms, ensuring high performance in frequency and temperature stability.
- Designed for operating temperatures ranging from -55°C to a maximum of 105°C.
- Long life expectancy with 2000 hours rated lifetime.
- Certified RoHS compliant ensuring environmentally safe material use.
Product Description
The Nichicon RL80J102MDN1KX is a 1 millifarad aluminium electrolytic capacitor designed for demanding electronic applications requiring reliable power filtering and signal smoothing. Its polar design and radial leads ensure secure and stable connections.
With a rated voltage of 6.3 volts and a compact form factor of 8mm diameter by 8mm height, this capacitor is suited to compact and high-density electronics assemblies. The 3.5mm lead pitch matches standard PCB hole spacing to simplify installation. It delivers exceptional ripple current handling capability of 5.7 amperes, supported by a low equivalent series resistance (ESR) of 9 milliohms which contributes to enhanced efficiency and lower heat generation.
Engineered to operate reliably across a broad temperature range from -55°C up to 105°C, the RL80J102MDN1KX offers longevity with an expected operational lifetime of 2000 hours under specified conditions. The capacitor complies with RoHS standards, ensuring it meets environmental regulation requirements.
1mF capacitance for power smoothing and filtering applications. Rated voltage: 6.3V polar electrolytic design. Radial can and lead through-hole mount type. Compact size: 8mm diameter and 8mm height with 3.5mm lead pitch.
High ripple current capacity: 5.7A. Low ESR of 9mΩ for performance stability. Temperature range: -55°C to +105°C for industrial applications. Long operational lifetime of 2000 hours. RoHS compliant and environmentally safe.
This capacitor is widely used in industrial electronics, power supplies, embedded systems, and audio/video equipment where stable capacitance and reliability are critical. Its robust construction supports continuous operation at elevated temperatures and frequencies.
Explore EnvMart categories for more electronic components and quality reliable capacitors ideal for your design and manufacturing needs.
Explore more products in our Aluminium Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Nichicon RL80J102MDN1KX capacitor has a capacitance of 1 millifarad (1mF).
This model operates at a rated voltage of 6.3 volts.
It supports a maximum ripple current of 5.7 amperes.
The capacitor has a diameter of 8mm and a height of 8mm, with a lead pitch of 3.5mm.
The equivalent series resistance (ESR) is 9 milliohms, contributing to its performance stability.
It operates reliably within a temperature range of -55°C to 105°C.
This capacitor has a rated lifetime of 2000 hours under specified conditions.
It features a polar construction with a radial can and radial lead termination for through-hole mounting.
Yes, the Nichicon RL80J102MDN1KX is certified RoHS compliant, ensuring it meets environmental regulations.
It is widely used in industrial electronics, power supplies, embedded systems, and audio/video equipment.
This capacitor is packaged in a box.
The tolerance for the Nichicon RL80J102MDN1KX is ±20%.
