Nichicon 22 F 2.7V DC Polar Electric Double Layer Supercapacitor ±20% Tolerance UM Series JUMT1226MHD
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 2.7V dc |
| Diameter | 16mm |
| Brand | Nichicon |
| Height | 31.5mm |
| Model | JUMT1226MHD |
| Depth | 31.5mm |
| Mount Type | Through Hole |
| Series | UM |
| Maximum Operating Temperature | 70°C |
| Tolerance | ±20 % |
| Lifetime | 1000 h |
| Capacitance | 22F |
| Minimum Operating Temperature | -25°C |
| Polarity | Polar |
| Terminal type | Solder |
| Leakage Current | 500μA |
| Standards/Approvals | RoHS 2011/65/EU |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 715-3520Brand: NichiconManufacturers Part No.: JUMT1226MHD |
| Pin Count | 2 |
| Lead Pitch | 7.5mm |
| Lead Diameter | 0.8mm |
| Equivalent Series Resistance ESR | 200mΩ |
| Capacitor Family | Electric Double Layer |
Key Features
- This supercapacitor offers a capacitance of 22 farads.
- It features a durable through-hole mount with lead diameter of 0.8 mm.
- The capacitor has a diameter of 16 mm and height of 31.5 mm.
- Designed for a wide temperature range from -25°C to 70°C.
- It has a leakage current of 500 microamperes and ESR of 200 milliohms.
- The component supports a lead pitch of 7.5 mm and solder terminal type.
- The rated lifetime is 1000 hours ensuring reliable performance.
- Manufactured in Japan adhering to RoHS 2011/65/EU standards.
Product Description
Nichicon JUMT1226MHD is a 22 F polar Electric Double Layer supercapacitor from the UM series, designed for 2.7 V DC operation. It is a through-hole mount component suitable for applications requiring rapid charge and discharge cycles.
Its construction features radial leads with a lead diameter of 0.8 mm and pitch of 7.5 mm, allowing easy soldering onto PCBs. The capacitor diameter is 16 mm with a height of 31.5 mm, making it compact and appropriate for space-constrained electronic assemblies.
The supercapacitor operates reliably under a wide temperature range from -25°C to 70°C, making it suitable for industrial, automotive, and consumer electronics environments where temperature variation can be significant.
This component shows a leakage current of 500 microamperes and an Equivalent Series Resistance (ESR) of 200 milliohms, delivering stable performance in memory backup, power stabilization, and energy storage applications.
The rated lifespan of 1000 hours supports continuous industrial usage, while compliance with RoHS 2011/65/EU directives ensures it meets environmental safety and quality standards. The capacitor is manufactured in Japan, reflecting high production quality.
Capacitance of 22 F for large energy storage capacity. Through-hole mount type with sturdy radial leads. Leakage current of 500 μA for improved efficiency. Operating temperature range from -25°C to 70°C for wider industrial usability.
ESR of 200 mΩ ensures effective charge/discharge cycles. Lifetime rating of 1000 hours for long-term reliability. Manufactured in Japan with RoHS compliance.
Ideal for electronic equipment requiring memory backup solutions, power conditioning, and energy harvesting. This UM series supercapacitor by Nichicon provides a reliable and efficient solution for engineers and designers across diverse industrial sectors.
Explore more Nichicon capacitors and Supercapacitors on EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance of 22 farads, providing a large energy storage capacity suitable for various applications.
It operates at a voltage of 2.7V DC, making it suitable for low-voltage applications.
The supercapacitor can operate within a temperature range of -25°C to 70°C, allowing it to function effectively in various environments.
The Equivalent Series Resistance (ESR) of this supercapacitor is 200 milliohms, which supports effective charge and discharge cycles.
It features a lead diameter of 0.8 mm and a lead pitch of 7.5 mm, facilitating easy soldering onto PCBs.
The leakage current for this supercapacitor is 500 microamperes, which contributes to its efficiency in energy storage applications.
This model uses a through-hole mount type, making it suitable for various electronic assembly applications.
The rated lifetime of this supercapacitor is 1000 hours, ensuring reliable performance in continuous applications.
Yes, it complies with RoHS 2011/65/EU standards, ensuring it meets environmental safety and quality requirements.
The supercapacitor has a diameter of 16 mm and a height of 31.5 mm, making it compact for space-constrained applications.
It is suitable for applications requiring rapid charge and discharge cycles, such as memory backup, power stabilization, and energy storage.
This supercapacitor is manufactured in Japan, reflecting high production quality.
