Nichicon XK Series Film Capacitor 680 nF 250V AC 630V DC Through Hole 2-Pin QXK2J684KTP
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Nichicon |
| Height | 20.1mm |
| Length | 25.5mm |
| Model | QXK2J684KTP |
| Width | 11.3mm |
| Mount Type | Through Hole |
| Series | XK |
| Maximum Operating Temperature | 105°C |
| Capacitance | 680nF |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Rated AC Voltage | 250V ac |
| Rated DC Voltage | 630V dc |
| Lead Pitch | 22.5mm |
| Lead Diameter | 0.8mm |
Key Features
- This capacitor features a capacitance of 680 nF for precise electrical performance.
- It is rated for 250V AC and 630V DC voltage, ensuring robust operation.
- The through-hole mount type with 2 pins and 22.5mm lead pitch provides easy PCB integration.
- Operating temperature goes up to 105°C, suitable for various industrial environments.
- Compact dimensions with length 25.5mm, width 11.3mm, and height 20.1mm support space-efficient designs.
- Lead diameter of 0.8mm ensures secure electrical connections.
- Manufactured in Japan under RoHS compliance for environmental safety.
Product Description
The Nichicon QXK2J684KTP Film Capacitor from the XK Series is a high-quality electronic component suitable for industrial and commercial electronic applications. It provides a capacitance of 680 nF and is rated for both 250V AC and 630V DC voltage, making it versatile for various power and signal conditioning circuits.
This capacitor utilizes a through-hole mount type with two pins spaced at a 22.5mm lead pitch, allowing for straightforward and durable placement on printed circuit boards. The pins have a lead diameter of 0.8mm, ensuring reliable mechanical and electrical connections during assembly.
With a maximum operating temperature of 105°C, this component can operate efficiently under demanding temperature conditions commonly found in manufacturing, automation, and measurement instruments. Its compact size with dimensions 25.5mm length, 11.3mm width, and 20.1mm height enables integration into space-constrained assemblies while maintaining performance.
Manufactured in Japan, the capacitor adheres to RoHS standards, reflecting its compliance with environmental regulations and quality assurance practices. The industrial-grade construction of the Nichicon XK Series capacitors supports consistent performance reliability and longevity.
Capacitance of 680 nF. Rated for 250V AC and 630V DC. Through-hole mount with 2 pins, 22.5mm lead pitch. Maximum operating temperature of 105°C. Compact dimensions: 25.5mm x 11.3mm x 20.1mm. Lead diameter of 0.8mm. RoHS compliant, made in Japan.
This film capacitor is ideal for use in electronic components manufacturing, power electronics, consumer electronics, and other industrial applications requiring reliable passive components. Explore more Nichicon capacitors in this category at EnvMart for your varied engineering needs.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance of 680 nF, providing precise electrical performance for various applications.
It is rated for 250V AC and 630V DC, making it suitable for different power and signal conditioning circuits.
The maximum operating temperature is 105°C, allowing it to function effectively in demanding environments.
This capacitor features a through-hole mount type with two pins, facilitating easy integration into printed circuit boards.
The dimensions are 25.5mm in length, 11.3mm in width, and 20.1mm in height, supporting space-efficient designs.
The lead pitch is 22.5mm, which is standard for many through-hole applications.
The lead diameter is 0.8mm, ensuring secure electrical connections during assembly.
Yes, it is RoHS compliant, reflecting adherence to environmental safety standards.
This model is manufactured in Japan, known for its high-quality electronic components.
It is suitable for various industrial applications, including electronic components manufacturing and power electronics.
This capacitor has 2 pins, which are designed for through-hole mounting.
